纽荷兰零件查询(DC100) - CRAWLER DOZER (N.A. VERSION) (4/00-) (9.600[02B]) - CAB DC100 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
526 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76598441 | [1] | SUPPORT | MAC |
| 2. | 76598442 | [1] | PAN | MAC |
| 3. | 76598443 | [1] | ELECTRIC PUMP | MAC |
| 4. | 76598444 | [1] | FUEL SYSTEM INJECTOR | MAC |
| 5. | 76598447 | [2] | GRILLE | TOR |
| 6. | 76598445 | [1] | COVER | MAC |
| 7. | 76598446 | [2] | SCREW | MAC |
| 8. | 76590872 | [6] | SCREW | MAC Superseded by part number: 120100 |
| 9. | 76598448 | [6] | LOCK WASHER | MACLOCK |
| 10. | 76598449 | [6] | WASHER | MAC |
| 11. | 76598450 | [1] | CEILING LAMP | MAC |
| 12. | 76591400 | [1] | BULB | MACLAMP Superseded by part number: 10863090 |
| 13. | 76598453 | [2] | WIPER MOTOR | MACMOTOR, WINDSHIELD WIPER |
| 14. | 76598454 | [2] | BALL STUD | MACBALL PIN |
| 15. | 76598455 | [2] | COMMUTATOR BRUSH | MACArm, Wiper LINKAGE |
| 16. | 76598456 | [1] | WIPER BLADE | MACBlade, Wiper BRUSH Superseded by part number: 76598895 |
| 17. | 76598457 | [1] | POWER SOCKET | MACRECEPTACLE |
| 18. | 76598458 | [2] | SCREW | MAC |
| 19. | 82003345 | [1] | WIPER BLADE | JESREAR WPER BLADE Superseded by part number: 73329275 |
| 22. | 76591395 | [4] | NUT | MACNUT |
| 23. | 76591401 | [8] | WASHER | MAC |
| 24. | 76591402 | [4] | SILENTBLOC | MACDAMPENER |
| 25. | 76591396 | [4] | SCREW | MAC |
| 26. | 76605390 | [1] | COVER | MACPANEL |
