纽荷兰零件查询(DC100) - CRAWLER DOZER (N.A. VERSION) (4/00-) (9.650[04]) - AIR-CONDITIONER SYSTEM DC70 - DC80 - DC100 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
225 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76605616 | [1] | HYDRAULIC VALVE | MAC |
| 3. | 76605617 | [1] | FLEXIBLE HOSE | MAC |
| 4. | 76605618 | [1] | FLEXIBLE HOSE | MAC Superseded by part number: 47323006 |
| 5. | 76605628 | [1] | HYD CONNECTOR | MAC |
| 6. | 76605629 | [1] | HYD CONNECTOR | MAC |
| 7. | 76605630 | [1] | FLEXIBLE HOSE | MAC |
| 8. | 76605631 | [1] | FLEXIBLE HOSE | MAC |
| 9. | 76605637 | [1] | FLANGE | MAC |
| 11. | 76605632 | [1] | FLEXIBLE HOSE | MAC |
| 12. | 76605638 | [1] | SUPPORT | MAC |
| 13. | 76605648 | [1] | CONDENSER | MAC- FILTER |
| 14. | 76590848 | [2] | NUT | MAC Superseded by part number: 15503611 |
| 15. | 76591364 | [2] | SCREW | MAC Superseded by part number: 628-8020 |
| 16. | 76605639 | [1] | SENSOR | MAC |
| 17. | 76605649 | [2] | SCREW | MAC Superseded by part number: 86574721 |
| 18. | 76605650 | [1] | AIRCOND. COMPRESSOR | MAC |
| 19. | 76605651 | [1] | BELT | MAC |
| 20. | 76605652 | [1] | PULLEY | MAC |
| 21. | 76605660 | [1] | SPACER | MAC |
| 22. | 76605653 | [1] | FIXING PLATE | MAC |
| 23. | 76591286 | [1] | SCREW | NH Superseded by part number: 86629541 |
| 24. | 76605654 | [1] | BRACKET | MAC |
| 25. | 76605655 | [2] | SPACER | MAC |
| 28. | 76590714 | [3] | SCREW | MAC Superseded by part number: 9515003 |
| 29. | 76590721 | [3] | LOCK WASHER | MAC |
| 30. | 76605640 | [1] | SUPPORT | MAC |
| 32. | 76605633 | [1] | FLEXIBLE HOSE | MAC |
| 33. | 76605656 | [1] | BLOWER | MAC |
| 34. | 76605646 | [1] | CONVEYOR | MAC |
| 35. | 76609800 | [1] | SUPPORT | MACSUPPORT |
| 36. | 76605657 | [3] | SCREW | MAC Superseded by part number: 87698790 |
| 38. | 76605647 | [1] | CONDENSER | MAC |
| 39. | 76609801 | [1] | SUPPORT | MACSUPPORT |
| 40. | 76605643 | [1] | SHIELD | MAC |
| 41. | 76605644 | [1] | SHIELD | MAC |
| 42. | 76605645 | [1] | SHIELD | MAC |
| 43. | 76605399 | [1] | SUPPORT | MAC |
| 44. | 76590929 | [1] | NUT | MAC Superseded by part number: 43362 |
| 45. | 76592899 | [1] | SCREW | MAC Superseded by part number: 16044024 |
| 46. | 76605658 | [1] | SCREW | MAC Superseded by part number: 76605809 |
| 47. | 76592867 | [4] | SCREW | MAC Superseded by part number: 83931335 |
| 49. | 76590934 | [3] | NUT | MAC Superseded by part number: 12574221 |
| 50. | 76605659 | [1] | SCREW | MAC |
| 51. | 47323002 | [1] | FLANGE | MACFLANGE |
| 52. | 47323003 | [1] | HYDRAULIC VALVE | MACVALVE |
| 53. | 47323004 | [1] | FLANGE | MACFLANGE |
| 54. | 47323005 | [1] | FLEXIBLE HOSE | MACHOSE |
| 55. | 47323006 | [1] | FLEXIBLE HOSE | MACHOSE |
