纽荷兰零件查询(DC100) - CRAWLER DOZER (N.A. VERSION) (4/00-) (9.651[01]) - CAB HEATER CIRCUIT WITH CANOPY DC70 - DC80 - DC100 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
1012 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76595933 | [8] | CLAMP | MAC Superseded by part number: 18088392 |
| 2. | 47323040 | [2] | U-BOLT | MAC |
| 3. | 47323041 | [1] | HEATER | MAC |
| 4. | 76590848 | [4] | NUT | MAC Superseded by part number: 15503611 |
| 5. | 76590847 | [4] | WASHER | MAC Superseded by part number: 10519624 |
| 6. | 76595938 | [1] | HYD CONNECTOR | MAC |
| 7. | 76591041 | [1] | HYD CONNECTOR | MAC |
| 8. | 76595939 | [1] | RIGID TUBE | MAC |
| 9. | 76595945 | [1] | HYD CONNECTOR | MAC |
| 10. | 47323042 | [2] | FLEXIBLE HOSE | MAC Superseded by part number: 78100216 |
| 11. | 76595947 | [1] | FLEXIBLE HOSE | MAC |
| 12. | 76595948 | [1] | HYD CONNECTOR | MAC |
| 13. | 76595949 | [1] | HYD CONNECTOR | MAC |
| 14. | 47323043 | [1] | DRAINCOCK/TAP SUPPLY | MAC |
| 15. | 76595951 | [1] | FLEXIBLE HOSE | MAC Superseded by part number: 78100216 |
| 16. | 76595952 | [1] | HYD CONNECTOR | MAC |
| 17. | 47323044 | [1] | HYD CONNECTOR | MAC |
| 18. | 47323045 | [1] | SUPPORT | MAC |
| 19. | 47323046 | [2] | U-BOLT | MAC |
| 20. | 47323047 | [1] | ELECTRIC CABLE | MAC |
| 21. | 47323048 | [1] | SWITCH | MAC |
| 22. | 47323049 | [2] | FLEXIBLE HOSE | MAC |
| 23. | 47323050 | [3] | NUT | MAC Superseded by part number: 10726721 |
| 24. | 47323051 | [1] | WASHER | MAC Superseded by part number: 11270460 |
| 25. | 76590934 | [4] | NUT | MAC Superseded by part number: 12574221 |
| 26. | 76590895 | [4] | WASHER | MAC Superseded by part number: 86639313 |
