现代零件查询20/25BR-7 REACH & ATTACH HYDRAULIC PIPING(NORMAL)EPC Hyundai _现代Hyundai_工程机械

现代零件查询20/25BR-7 REACH & ATTACH HYDRAULIC PIPING(NORMAL)EPC Hyundai

广数供应链运营团队, 14 02月, 2025，浏览： 398 次

Pos.	Part No	Qty	Parts name	Comments
2.	X515-109524	[2]	CONNECTOR-LONG,ORFS	20BR
2.	X515-109524	[1]	CONNECTOR-LONG,ORFS
2.	X515-109524	[2]	CONNECTOR-LONG,ORFS	25BR
3.	31FG-80410	[2]	CONNECTOR-ORFS	20BR
3.	31FG-80410	[1]	CONNECTOR-ORFS
3.	31FG-80410	[2]	CONNECTOR-ORFS	25BR
4.	P930-064036	[2]	HOSE ASSY-ORFS 0X90
6.	31HH-10020	[2]	CLAMP-HOSE
7.	S035-084526	[2]	BOLT-W/WASHER
8.	X515-109514	[1]	CONNECTOR-LONG,ORFS	4-SPOOL, 25BR
9.	31FS-70040	[1]	CONNECTOR-ORFS	4-SPOOL, 25BR
10.	P930-063047	[1]	HOSE ASSY-ORFS 0X90	4-SPOOL, 20BR
10.	P930-044047	[1]	HOSE ASSY-ORFS 0X90	4-SPOOL
10.	P930-063047	[1]	HOSE ASSY-ORFS 0X90	4-SPOOL, 25BR
11.	P930-063046	[1]	HOSE ASSY-ORFS 0X90	4-SPOOL, 20BR
11.	P930-044046	[1]	HOSE ASSY-ORFS 0X90	4-SPOOL
11.	P930-063046	[1]	HOSE ASSY-ORFS 0X90	4-SPOOL, 25BR
12.	31FS-30010	[1]	MANIFOLD-ATTACH	20BR
12.	31FS-30010	[1]	MANIFOLD-ATTACH	25BR
13.	31FS-30030	[1]	BRACKET	20BR
13.	31FS-30030	[1]	BRACKET	25BR
14.	31FS-30040	[1]	COVER WA	20BR
14.	31FS-30040	[1]	COVER WA	25BR
15.	31FS-30050	[1]	PIPE ASSY	20BR
15.	31FS-30050	[1]	PIPE ASSY	25BR
16.	31FS-30060	[1]	PIPE ASSY	20BR
16.	31FS-30060	[1]	PIPE ASSY	25BR
17.	31FG-70030	[2]	ELBOW-90	20BR
17.	31FG-70030	[2]	ELBOW-90	25BR
18.	S035-082026	[4]	BOLT-W/WASHER	20BR
18.	S035-082026	[4]	BOLT-W/WASHER	25BR
19.	909267100-DA	[4]	BOLT	20BR
19.	909267100-DA	[4]	BOLT	25BR
20.	S403-08200B	[2]	WASHER-PLAIN	20BR
20.	S403-08200B	[2]	WASHER-PLAIN	25BR
