凯斯零件查询(RBX451) - CASE IH ROUND BALER (12/01-10/02) (047) - WIDE PICKUP, STUFFER FEEDER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
647 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
617667R92
|
[1] |
BALL BEARING,31.75mm ID x 62mm OD x 18mm W
|
CAS
Superseded by part number: 84484181
|
| 2. |
86636169
|
[2] |
FLANGED BEARING
|
NH
Bearing
|
| 3. |
905-10020
|
[3] |
BOLT,Hex Flg, M10 x 20mm
|
CAS
Superseded by part number: 274249
|
| 4. |
86634610
|
[1] |
COUNTERWEIGHT
|
NH
|
| 5. |
126-24
|
[2] |
WOODRUFF KEY,#15, 1/4" x 1"
|
CAS
Superseded by part number: 47471
|
| 6. |
204807C91
|
[2] |
BEARING ASSY,25.4mm ID x 52mm OD x 15mm W
|
CAS
Ball
|
| 7. |
86636651
|
[2] |
COVER
|
NH
|
| 8. |
178514
|
[2] |
WASHER
|
NH
Plastic, 1"
|
| 9. |
86634561
|
[1] |
FEEDER
|
NH
|
| 10. |
86509398
|
[1] |
SHAFT
|
NH
|
| 11. |
86634609
|
[1] |
ARM
|
NH
|
| 12. |
86634527
|
[1] |
ARM
|
NH
Includes: Ref. 13 & 14 Superseded by part number: 87043492
|
| 13. |
T39594
|
[2] |
BALL BEARING,0.7505" ID x 1.7805" OD x 0.61"
|
CAS
Superseded by part number: 87029275
|
| 14. |
100-21175
|
[2] |
SNAP RING,1.75", Int, #175
|
CAS
Superseded by part number: 66967
|
| 15. |
87644323
|
[4] |
SPACER,19.18mm ID x 28.54mm OD x 7.75mm Thk
|
NH
|
| 16. |
600083
|
[1] |
WASHER,19.3mm ID x 28.7mm OD x 1.36mm Thk
|
NH
1-1/4" OD
|
| 17. |
413-1248
|
[1] |
BOLT,Hex, 3/4" - 10 x 3", Gr 5
|
CAS
Superseded by part number: 87337
|
| 18. |
232-41412
|
[2] |
LOCK NUT,3/4"-10, GC
|
CAS
Superseded by part number: 280375
|
| 19. |
413-1240
|
[1] |
BOLT,Hex, 3/4" - 10 x 2-1/2", Gr 5
|
CAS
Superseded by part number: 9706701
|
| 20. |
455102R21
|
[2] |
COLLAR
|
IH
Superseded by part number: 47577183
|
