凯斯零件查询(RBX451) - CASE IH ROUND BALER (12/01-10/02) (048) - WIDE PICKUP, JAW CLUTCH Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
894 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
86635012
|
[2] |
FLANGE
|
NH
Bearing
|
| 2. |
614-10020
|
[3] |
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 43138
|
| 3. |
571588R92
|
[1] |
BALL BEARING,1.3755" ID x 72 mm OD x 1"
|
IH
Superseded by part number: 47066
|
| 4. |
517645R11
|
[1] |
COLLAR
|
IH
Locking, Includes: Set Screw Superseded by part number: 47577188
|
| 5. |
126-33
|
[1] |
WOODRUFF KEY,#D, 5/16" x 1 1/4"
|
CAS
Superseded by part number: 87831
|
| 6. |
86543306
|
[1] |
SHAFT
|
NH
Superseded by part number: 87700673, 87718116
|
| 7. |
86637255
|
[1] |
SPROCKET ASSY.
|
NH
Includes: Ref. 7A Superseded by part number: 87047934
|
| 8. |
714379
|
[2] |
CLUTCH
|
NH
Jaw Superseded by part number: 87639816
|
| 9. |
86637169
|
[1] |
HUB
|
NH
|
| 10. |
9822385
|
[6] |
BELLEVILLE WASHER,52mm ID x 100mm OD x 3.3mm Thk
|
NH
|
| 11. |
166490
|
[1] |
WASHER,51.6mm ID x 76.2mm OD x 3.68mm Thk
|
NH
Hardened, 2"
|
| 12. |
9845592
|
[1] |
RING
|
NH
Superseded by part number: 84266202
|
| 13. |
46962
|
[1] |
BUSHING,2" ID x 2.13" OD x 1.25" L
|
NH
|
| 14. |
88775
|
[1] |
LUBE NIPPLE,1/4"-28
|
NH
|
| 15. |
86567296
|
[1] |
WASHER
|
NH
Nylon, M100 Superseded by part number: 87033387
|
| 16. |
280215
|
[1] |
SLOTTED NUT,1 1/8"-12, G5
|
NH
|
| 17. |
26558
|
[1] |
WASHER,28.5mm ID x 45.2mm OD x 1.7mm Thk
|
NH
1-3/4" OD
|
