凯斯零件查询(RBX451) - CASE IH ROUND BALER (12/01-10/02) (012) - DRIVE ROLLER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
358 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
614-12040
|
[1] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 86629541
|
| 2. |
87030468
|
[1] |
HUB
|
PA
Superseded by part number: 87398962
|
| 3. |
54185
|
[1] |
WASHER
|
NH
2-1/2" OD
|
| 4. |
86516311
|
[1] |
SUPPORT
|
NH
|
| 5. |
8050825
|
[1] |
BEARING, ROLLER, CYL,38.1 mm ID x 80 mm OD x 30.163 mm
|
L
Superseded by part number: F82059
|
| 6. |
86637321
|
[1] |
ROLLER
|
NH
Drive
|
| 7. |
86635219
|
[1] |
COVER
|
NH
|
| 8. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Bearing
|
| 9. |
86554713
|
[1] |
BEARING ASSY
|
NH
Includes: Ref. 8
|
| 10. |
86568253
|
[1] |
COLLAR
|
NH
Locking, for Ref. 8 Superseded by part number: 618032R11
|
| 11. |
86637269
|
[1] |
DRIVEN SPROCKET,RC80, 22T
|
NH
22T
|
| 12. |
87483
|
[1] |
KEY,0.31" x 1.5" L
|
NH
5/16" Sq. x 1-1/2"
|
| 13. |
492-11044
|
[4] |
LOCK WASHER,7/16"
|
CAS
Superseded by part number: 81547
|
| 14. |
814-10040
|
[4] |
BOLT,Hex, M10 x 1.5 x 40mm, Cl 8.8
|
CAS
Superseded by part number: 120112
|
| 15. |
425-146
|
[2] |
JAM NUT,3/8" - 16, Gr 5
|
CAS
Superseded by part number: 87016560
|
| 16. |
86542824
|
[2] |
SET SCREW,Sq Hd, 3/8" - 16 x 1-1/2"
|
NH
Cup Pt
|
| 17. |
9848489
|
[1] |
BEARING ASSY,73 mm ID x 132.1976 mm OD x 38.10 mm, Round Bore
|
NH
Includes: Ref. 5 Superseded by part number: 47531138
|
| 18. |
614-10030
|
[1] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 43140
|
| 20. |
136443
|
[1] |
WASHER,10.32mm ID x 57.15mm OD x 4.8mm Thk
|
NH
3/8"
|
