| 3. |
515-2279
|
[7] |
CLAMP,5/16", Insul, 5/16" Bolt
|
CAS
Superseded by part number: 853764
|
| 18. |
86624226
|
[1] |
HARNESS
|
NH
Wire, Main
|
| 20. |
86637389
|
[2] |
SPRING
|
NH
Bale Shape
|
| 21. |
86509329
|
[2] |
MOUNTING PLATE
|
NH
Superseded by part number: 87362420
|
| 22. |
86619565
|
[2] |
SUPPORT
|
NH
|
| 23. |
86637391
|
[2] |
ARM
|
NH
|
| 24. |
217465
|
[2] |
SPRING
|
NH
Extension
|
| 25. |
177822
|
[2] |
SPACER,8.33mm ID x 12.7mm OD x 4.32mm Thk
|
NH
21/64" ID x .500" OD x .170" Lg.
|
| 26. |
86500902
|
[2] |
POTENTIOMETER,3000 Ohm, 16 VDC
|
NH
Bale Shape Superseded by part number: 86977396
|
| 27. |
718782
|
[4] |
SPACER
|
NH
|
| 28. |
86506979
|
[1] |
SHIELD
|
NH
LH
|
| 40. |
614-4020
|
[4] |
BOLT,Hex, M4 x 0.7 x 20mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 412255
|
| 42. |
614-8020
|
[6] |
BOLT,Hex, M8 x 1.25 x 20mm
|
CAS
Superseded by part number: 120104
|
| 46. |
905-8016
|
[6] |
BOLT,Hex Flg, M8 x 16mm
|
CAS
Superseded by part number: 86511478
|
| 48. |
433-548
|
[4] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3", Gr 5
|
CAS
Superseded by part number: 281006
|
| 50. |
86613601
|
[2] |
WASHER,14.88mm ID x 28.69mm OD x 7.35mm Thk
|
NH
Urethane
|
| 57. |
495-21038
|
[2] |
WASHER,5/16"
|
CAS
Superseded by part number: 80664, 72187263
|
| 60. |
322358
|
[8] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 61. |
492-11031
|
[2] |
LOCK WASHER,5/16"
|
CAS
Superseded by part number: 83990583
|
| 62. |
425-105
|
[4] |
NUT,5/16"-18, G5
|
CAS
Superseded by part number: 9635082, 72187221
|
| 63. |
825-1408
|
[4] |
NUT,M8, Cl 8
|
CAS
Superseded by part number: 43362
|
| 65. |
231-5145
|
[1] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
Superseded by part number: 72187067, 145458
|
| 67. |
825-5148
|
[4] |
SERRATED NUT,M8, Flg Ser
|
CAS
Superseded by part number: 86505868
|
| 73. |
100-3437
|
[2] |
SNAP RING,#37, Ext
|
CAS
Superseded by part number: 86000439
|
