凯斯零件查询(RBX451) - CASE IH ROUND BALER (12/01-10/02) (017) - BALE EJECTOR Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
458 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87027503
|
[1] |
EJECTOR
|
PA
Bale
|
| 2. |
86562970
|
[2] |
BUSHING,19.3mm ID x 41.61mm OD x 40.1mm L
|
NH
Urethane
|
| 3. |
86637308
|
[2] |
ROD
|
NH
Superseded by part number: 87028071
|
| 4. |
426-524
|
[2] |
BOLT,Hex, 5/16" - 18 x 1-1/2", Gr 8
|
CAS
Superseded by part number: 86514369
|
| 5. |
280736
|
[2] |
NUT,5/16"-18, GC
|
NH
|
| 6. |
86617511
|
[4] |
WASHER,19.84mm ID x 38.1mm OD x 4.78mm Thk
|
NH
1-1/2" OD
|
| 7. |
86637296
|
[2] |
PIN
|
NH
Superseded by part number: 87028069
|
| 8. |
621022
|
[4] |
SPRING
|
NH
9.7" Long
|
| 9. |
825-51412
|
[4] |
FLANGE NUT,M12, Flg Ser
|
CAS
Superseded by part number: 43436
|
| 10. |
647765
|
[4] |
SPACER
|
NH
Superseded by part number: 87022950
|
| 11. |
814-12090
|
[4] |
BOLT,Hex, M12 x 1.75 x 90mm, Cl 8.8
|
CAS
Superseded by part number: 86508581
|
