| 1. |
86620777
|
[1] |
SHIELD
|
PA
RH
|
| 2. |
86620776
|
[1] |
SHIELD
|
NH
RH, Corner Superseded by part number: 86620767
|
| 3. |
86629129
|
[1] |
SHIELD
|
NH
RH
|
| 4. |
9617869
|
[3] |
BUMPER,28.4mm W x 31.8mm L x 4.8mm Thk
|
NH
Rubber, 3/16" Thk
|
| 5. |
86610200
|
[16] |
THREADED INSERT,M8 x 1.25
|
NH
M8
|
| 6. |
86637008
|
[1] |
ANGLE
|
PA
Superseded by part number: 86615439
|
| 7. |
84100271
|
[2] |
HINGE
|
ZED
Lower, Triangular-Shaped
|
| 7. |
87037410
|
[2] |
HINGE
|
PA
Lower, Square-Shaped
|
| 8. |
86628347
|
[2] |
STUD,M8 x 36.5mm OAL, 10mm OD Ball
|
NH
Long, Ball End
|
| 9. |
86634307
|
[2] |
STUD
|
NH
Short, Ball End Superseded by part number: 87603835
|
| 10. |
86628348
|
[2] |
GAS STRUT
|
NH
|
| 11. |
86837233
|
[1] |
HINGE
|
PA
|
| 12. |
87019802
|
[1] |
DOOR
|
PA
RH, North America, Includes: Ref. 31 & 33
|
| 12. |
87041544
|
[1] |
DOOR ASSY.
|
PA
RH, North America, Includes: Ref. 31 & 33
|
| 12. |
87030543
|
[1] |
DOOR
|
PA
RH, Europe & R.O.W., Decals Ref. 31 & 33 are Not Included.
|
| 12. |
87041540
|
[1] |
DOOR ASSY.
|
PA
RH, Europe & R.O.W., Decals Ref. 31 & 33 are Not Included.
|
| 13. |
86837232
|
[1] |
HINGE
|
PA
|
| 14. |
86979611
|
[1] |
ANGLE
|
NH
162mm Lg.
|
| 14. |
87038687
|
[1] |
ANGLE
|
PA
168mm Lg.
|
| 15. |
86637475
|
[1] |
ANGLE
|
NH
140mm Lg. Superseded by part number: 87037609
|
| 15. |
87037609
|
[1] |
ANGLE
|
PA
145mm Lg.
|
| 16. |
86620787
|
[1] |
PANEL
|
PA
RH Superseded by part number: 87047013
|
| 17. |
86610198
|
[5] |
INSERT,M6 x 1
|
NH
Threaded, M6
|
| 18. |
87019104
|
[1] |
PLATE
|
PA
Shim, Door Hinge
|
| 19. |
677808
|
[2] |
SELF-TAP SCREW,Hex Flng, 1/4" - 20 x 5/8"
|
NH
HWH, 1/4"-20 x 5/8"
|
| 20. |
9804256
|
[5] |
BOLT,Hex, M6 x 1 x 20mm, Full Thd, Cl 8.8
|
NH
|
| 21. |
844-8020
|
[23] |
BOLT,Hvy Hex, M8 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 9804258
|
| 22. |
814-8080
|
[2] |
BOLT,Hex, M8 x 1.25 x 80mm, Cl 8.8
|
CAS
Superseded by part number: 43133
|
| 22. |
814-8070
|
[2] |
BOLT,Hex, M8 x 1.25 x 70mm, Cl 8.8
|
CAS
Superseded by part number: 7120024
|
| 23. |
811-8020
|
[11] |
CARRIAGE BOLT,Sht Sq Nk, M8 x 1.25 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 86507486
|
| 25. |
814-8060
|
[1] |
BOLT,Hex, M8 x 1.25 x 60mm, Cl 8.8
|
CAS
Superseded by part number: 120061
|
| 25. |
814-8050
|
[1] |
BOLT,Hex, M8 x 1.25 x 50mm, Cl 8.8
|
CAS
Superseded by part number: 43130
|
| 26. |
322358
|
[34] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 28. |
825-2408
|
[22] |
FLANGE NUT,M8 x 1.25, Flg, Cl 8
|
CAS
Superseded by part number: 86505868
|
| 29. |
832-46408
|
[2] |
NUT,M8 x 1.25, Cl 8
|
CAS
Superseded by part number: 86528579
|
| 30. |
322357
|
[7] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 31. |
86631518
|
[1] |
DANGER DECAL
|
NH
English
|
| 31. |
86632801
|
[1] |
DECAL
|
NH
DANGER, French
|
| 33. |
86626958
|
[1] |
WARNING DECAL
|
NH
English
|
| 33. |
86626961
|
[1] |
WARNING DECAL
|
PA
French
|
