神钢零件查询(F4GE9484D J601) - ENGINE - 5801370290 - 84301930.. (1/07-12/07) (0668.016) - ROCKER SHAFT Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
943 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4895195 | [4] | ROCKER | TORROCKER SHAFT, ASSY |
| 2. | 4895361 | [8] | PUSH ROD | TORPUSHROD |
| 3. | 2852866 | [4] | BOLT,Flng, M8 x 1.25 x 75mm, Cl 8.8 | TORHEXAGON BOLT, M8X1,25X60 MM Superseded by part number: 504067723 |
| 4. | 4892860 | [4] | BOLT,Flng, M12 x 1.75 x 183mm | TORHEXAGON BOLT, M12X1,75 |
| 5. | 4895363 | [8] | SNAP RING | TORCIRCLIP |
| 6. | 4895364 | [8] | WASHER | TORWASHER |
| 7. | 4895196 | [4] | ROCKER ARM,Exhaust | TORROCKER ARM, ASSY |
| 8. | 4895365 | [8] | INSERT | TORBALL-END PIN Superseded by part number: 4895196, 4895196, 4895200 |
| 9. | 4895198 | [8] | NUT,3/8"-24, Heavy | LECHEXAGON NUT Superseded by part number: |
| 10. | 4895199 | [8] | ADJUSTMENT SCREW,3/8" - 24 x 25.85mm | TORROCKER ARM SCREW |
| 11. | 4895200 | [4] | ROCKER ARM,Intake | TORROCKER ARM, ASSY |
| 12. | 4895204 | [4] | SHAFT | TORROCKER BRACKET |
