神钢零件查询(F4GE9484D J601) - ENGINE - 5801370290 - 84301930.. (1/07-12/07) (0801.010) - CRANK SHAFT Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
562 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | 4893386 | [1] | GEAR,36 T | TORCAMSHAFT PINION |
| 3. | 2995787 | [4] | SET OF STD MAIN BRGS | TORMAIN BEARING STD. |
| 4. | 2995788 | [4] | SET OF MAIN BRGS-.25 | TORMAIN BEARING-0,250 Superseded by part number: |
| 5. | 2995789 | [4] | SET OF MAIN BRGS - | TORMAIN BEARING-0,500 |
| 6. | 2995785 | [1] | SET OF MAIN BRGS-.25 | TORMAIN BEARING-0,250, THRUST |
| 7. | 2995784 | [1] | SET OF THRUST WASHER | TORMAIN BEARING STD., THRUST |
| 8. | 2995786 | [1] | SET OF THRUST WASHER | TORMAIN BEARING-0,500, THRUST |
| 9. | 4899046 | [1] | DOWEL,M6 x 9 L | TORDOWEL PIN |
