神钢零件查询(F4GE9484D J601) - ENGINE - 5801370290 - 84301930.. (1/07-12/07) (0810.116) - CONNECTING ROD Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
590 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2831298 | [4] | CONNECTING ROD | TORCONN.ROD ASSY., ASSY |
| 2. | 4892708 | [4] | BUSHING,38.02mm ID x 41.01mm OD x 33.4mm L | TORBIG-END BUSH |
| 3. | 2831297 | [8] | FLANGE BOLT,Hex, M10 x 1.25 x 52mm, Cl 10.9 | TORCYLIND-HEAD SCREW |
| 4. | 8093882 | [4] | BEARING SET | TORCON.ROD BEAR STD. |
| 5. | 8094960 | [4] | BEARING SET,(-0.250) | TORCON.ROD BEAR-0,250 |
| 6. | 8094961 | [4] | BEARING SET,(-0.500) | TORCON.ROD BEAR-0,500 |
