| 1. |
86632879
|
[1] |
CHANNEL
|
NH
Superseded by part number: 87663907
|
| 2. |
9614538
|
[1] |
SPRING
|
NH
Extension
|
| 3. |
86602143
|
[2] |
WEAR PLATE
|
NH
|
| 4. |
86602046
|
[2] |
PLATE
|
NH
|
| 5. |
86602047
|
[2] |
PIVOT PLATE
|
NH
Superseded by part number: 87660305
|
| 6. |
86602446
|
[2] |
ANGLE
|
NH
|
| 7. |
86626477
|
[1] |
SPROCKET,29T / 39T
|
NH
Double, 29T & 39T Superseded by part number: 87047645
|
| 8. |
86624254
|
[2] |
STOP
|
NH
|
| 9. |
86628567
|
[1] |
EYEBOLT
|
NH
G2, 3/8"-16 x 8-3/4"
|
| 10. |
86512547
|
[1] |
SPRING,Extension, 1.94" OD x 13 - 1/8" L
|
NH
Extension
|
| 11. |
86500987
|
[1] |
SPACER
|
NH
|
| 12. |
86566303
|
[1] |
SPRING
|
NH
|
| 13. |
616723
|
[1] |
EYEBOLT
|
NH
G2, 3/8"-16 x 5"
|
| 14. |
87010534
|
[1] |
SHIELD
|
PA
|
| 15. |
0C
|
[2] |
ORDER COMPONENTS
|
NH
Pickup Wheel & Arm
|
| 16. |
87028747
|
[2] |
PLUG
|
PA
Plastic, for 1" Dia. Hole
|
| 17. |
86619277
|
[2] |
SHIELD
|
NH
|
| 18. |
854719
|
[2] |
CLIP
|
NH
Spring
|
| 20. |
213404
|
[5] |
SPACER,10.3mm ID x 38.1mm OD x 5.2mm OAL
|
NH
3/16" x 13/32" ID x 1-1/2" OD
|
| 21. |
87012266
|
[1] |
STRAP
|
PA
|
| 22. |
86637305
|
[2] |
LINK
|
NH
Shock Absorber
|
| 23. |
164936
|
[1] |
CHAIN
|
NH
RC60, 3/4"-pitch, 62 Pitches, Includes (1) 25812 Connecting Link Superseded by part number: 611362R91X
|
| 24. |
86570492
|
[1] |
SHOCK ABSORBER
|
NH
|
| 25. |
86636647
|
[1] |
SPRING NUT
|
NH
Spring
|
| 26. |
87015686
|
[1] |
BOLT
|
PA
Cap, HH, G5, 1/2"-13 x 10-1/2"
|
| 27. |
614-10020
|
[2] |
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 43138
|
| 28. |
614-10030
|
[1] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 43140
|
| 29. |
814-10080
|
[2] |
BOLT,Hex, M10 x 1.5 x 80mm, Cl 8.8
|
CAS
Superseded by part number: 129796A1
|
| 30. |
614-12040
|
[5] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 86629541
|
| 31. |
120248
|
[1] |
BOLT,Hex, M16 x 100, 8.8, Full Thd
|
PA
|
| 32. |
433-828
|
[4] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 3/4", Gr 5
|
CAS
Superseded by part number: 88530
|
| 33. |
381014
|
[8] |
SCREW,Flng, M8 x 16mm
|
NH
HWH, M8 x 1.25 x 16
|
| 34. |
374895
|
[6] |
CARRIAGE BOLT,M12 x 1.75 x 25mm, Cl 8.8
|
NH
|
| 35. |
287129
|
[1] |
SPECIAL WASHER
|
NH
Spacer, 3/8" ID, .294" Thk, Hardened
|
| 36. |
65319
|
[17] |
WASHER,13.1mm ID x 25.4mm OD x 3.68mm Thk
|
NH
|
| 37. |
692300
|
[1] |
WASHER,13.5mm ID x 50.8mm OD x 7.37mm Thk
|
NH
2" OD x 3/16" Thk
|
| 38. |
80679
|
[4] |
LOCK WASHER,1/20.507 CST ZND
|
NH
|
| 39. |
140045
|
[1] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 40. |
140046
|
[6] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 41. |
9827956
|
[1] |
WASHER,10.3mm ID x 25.4mm OD x 2.67mm Thk
|
NH
Hardened, 3/8"
|
| 42. |
86509499
|
[2] |
JAM NUT,3/8"-16, G2
|
ZED
|
| 43. |
425-106
|
[4] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 44. |
425-108
|
[7] |
NUT,1/2" - 13, Gr 5
|
CAS
Superseded by part number: 280431
|
| 45. |
825-1410
|
[2] |
NUT,M10, Cl 8
|
CAS
Superseded by part number: 100016
|
| 46. |
825-1412
|
[6] |
NUT,M12, Cl 8
|
CAS
Superseded by part number: 9706685
|
| 47. |
832-46410
|
[1] |
NUT,M10 x 1.5, Cl 8
|
CAS
Superseded by part number: 100037
|
| 48. |
832-46412
|
[4] |
NUT,M12 x 1.75, Cl 8
|
CAS
Superseded by part number: 100038
|
| 49. |
832-46416
|
[1] |
NUT,M16 x 2, Cl 8
|
CAS
Superseded by part number: 86000441
|
| 50. |
825-2406
|
[1] |
FLANGE NUT,M6 x 1, Cl 8.8
|
CAS
Superseded by part number: 9804276
|
| 51. |
495-21044
|
[6] |
WASHER,3/8"
|
CAS
Superseded by part number: 87779090, 80702
|
| 52. |
87017232
|
[1] |
SHIELD
|
PA
|
| 54. |
322357
|
[1] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 55. |
844-6020
|
[1] |
BOLT,Hvy Hex, M6 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 9804256
|
| 56. |
165271
|
[1] |
DRIVEN SPROCKET
|
NH
15T Idler Superseded by part number: 86627870, 80165271
|
