| 1. |
87038218
|
[1] |
PICK-UP
|
PA
1.5M Wide Dual Cam, Also Includes: Fig. 13.245 for Additional Components.
|
| 2. |
87758679
|
[2] |
FLANGED BEARING
|
PA
Superseded by part number: 87758678
|
| 3. |
617668R92
|
[1] |
BEARING ASSY,1.2505" ID x 62 mm OD x 0.9375"
|
IH
Ball Superseded by part number: 84484181
|
| 4. |
86634610
|
[1] |
COUNTERWEIGHT
|
NH
|
| 5. |
126-24
|
[2] |
WOODRUFF KEY,#15, 1/4" x 1"
|
CAS
Superseded by part number: 47471
|
| 6. |
814-12080
|
[3] |
BOLT,Hex, M12 x 1.75 x 80mm, Cl 8.8
|
CAS
Superseded by part number: 43158
|
| 7. |
832-46412
|
[6] |
NUT,M12 x 1.75, Cl 8
|
CAS
Superseded by part number: 100038
|
| 8. |
214366C91
|
[7] |
BALL BEARING,25.40mm ID x 52mm OD
|
IH
Ball Superseded by part number: 204807C91
|
| 9. |
86634561
|
[1] |
FEEDER
|
NH
Stuffer
|
| 10. |
86509398
|
[1] |
SHAFT
|
NH
|
| 11. |
86634609
|
[1] |
ARM
|
NH
|
| 12. |
86634527
|
[1] |
ARM
|
NH
Superseded by part number: 87043492
|
| 13. |
232-41412
|
[2] |
LOCK NUT,3/4"-10, GC
|
CAS
Superseded by part number: 280375
|
| 14. |
455102R21
|
[7] |
COLLAR
|
IH
Locking, Includes: Set Screw Superseded by part number: 47577183
|
| 15. |
718013
|
[4] |
SPACER
|
NH
|
| 16. |
413-1248
|
[1] |
BOLT,Hex, 3/4" - 10 x 3", Gr 5
|
CAS
Superseded by part number: 87337
|
| 17. |
413-1240
|
[1] |
BOLT,Hex, 3/4" - 10 x 2-1/2", Gr 5
|
CAS
Superseded by part number: 9706701
|
| 18. |
87644323
|
[1] |
SPACER,19.18mm ID x 28.54mm OD x 7.75mm Thk
|
NH
7/8" OD
|
| 20. |
557995R11
|
[1] |
COLLAR
|
IH
Locking, Includes: Set Screw Superseded by part number: 47508396
|
| 21. |
86635012
|
[2] |
FLANGE
|
NH
Bearing
|
| 22. |
571588R92
|
[1] |
BALL BEARING,1.3755" ID x 72 mm OD x 1"
|
IH
Superseded by part number: 47066
|
| 23. |
517645R11
|
[1] |
COLLAR
|
IH
Locking, Includes: Set Screw Superseded by part number: 47577188
|
| 24. |
614-10020
|
[6] |
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 43138
|
| 25. |
86567296
|
[1] |
WASHER
|
NH
M100, Nylon Superseded by part number: 87033387
|
| 26. |
86977787
|
[1] |
SHAFT
|
NH
Clutch, 419mm Lg. Superseded by part number: 87718115, 87700673
|
| 27. |
905-10020
|
[14] |
BOLT,Hex Flg, M10 x 20mm
|
CAS
Superseded by part number: 274249
|
| 28. |
87644538
|
[15/AR] |
SPACER,19.558mm ID x 28.702mm OD x 1.36mm W
|
NH
|
| 29. |
T39594
|
[2] |
BALL BEARING,0.7505" ID x 1.7805" OD x 0.61"
|
CAS
Superseded by part number: 87029275
|
| 30. |
46962
|
[1] |
BUSHING,2" ID x 2.13" OD x 1.25" L
|
NH
|
| 31. |
126-33
|
[1] |
WOODRUFF KEY,#D, 5/16" x 1 1/4"
|
CAS
Superseded by part number: 87831
|
| 32. |
86637255
|
[1] |
SPROCKET ASSY.
|
NH
Superseded by part number: 87047934
|
| 33. |
714379
|
[2] |
CLUTCH
|
NH
Jaw Superseded by part number: 87639816
|
| 34. |
86637169
|
[1] |
HUB
|
NH
|
| 35. |
9822385
|
[5] |
BELLEVILLE WASHER,52mm ID x 100mm OD x 3.3mm Thk
|
NH
|
| 36. |
9845592
|
[1] |
RING
|
NH
Superseded by part number: 84266202
|
| 37. |
280215
|
[1] |
SLOTTED NUT,1 1/8"-12, G5
|
NH
|
| 38. |
432-1228
|
[1] |
COTTER PIN,3/16" x 1 3/4"
|
CAS
Superseded by part number: 87399
|
| 39. |
86639836
|
[2] |
COVER
|
NH
|
| 40. |
166490
|
[1] |
WASHER,51.6mm ID x 76.2mm OD x 3.68mm Thk
|
NH
2", Hardened
|
| 41. |
86634558
|
[1] |
SUPPORT ASSY.
|
NH
RH
|
| 42. |
86837216
|
[1] |
FRAME
|
NH
Pickup
|
| 43. |
86634556
|
[1] |
SUPPORT ASSY.
|
NH
LH
|
| 44. |
825-51410
|
[19] |
FLANGE NUT,M10, Flg Ser
|
CAS
Superseded by part number: 43435
|
| 45. |
825-1408
|
[6] |
NUT,M8, Cl 8
|
CAS
Superseded by part number: 43362
|
| 46. |
811-8020
|
[13] |
CARRIAGE BOLT,Sht Sq Nk, M8 x 1.25 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 86507486
|
| 47. |
825-5148
|
[19] |
SERRATED NUT,M8, Flg Ser
|
CAS
Superseded by part number: 86505868
|
| 48. |
811-10020
|
[5] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 86512422
|
| 49. |
219-87
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
Superseded by part number: 87414
|
| 50. |
140046
|
[1] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 51. |
495-11053
|
[1] |
WASHER,1/2", SAE
|
CAS
Superseded by part number: 87364, 72187259
|
| 52. |
86631123
|
[1] |
SPACER,12.95mm ID x 19.05mm OD x 27mm L
|
NH
|
| 53. |
165271
|
[1] |
DRIVEN SPROCKET
|
NH
Idler, 15T Superseded by part number: 86627870, 80165271
|
| 54. |
86705271
|
[1] |
SPACER,13.5mm ID x 25.4mm OD x 34mm L
|
NH
|
| 55. |
86636654
|
[1] |
ARM
|
NH
|
| 56. |
86636651
|
[2] |
COVER
|
NH
|
| 57. |
178514
|
[2] |
WASHER
|
NH
|
