神钢零件查询(F4GE9484D J601) - ENGINE - 5801370290 - 84301930.. (1/07-12/07) (0820.193) - PISTON ASSY - PISTON RINGS - PISTON PIN Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
238 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 8094739 | [4] | PISTON RINGS KIT | TORPISTONRING SET STD Superseded by part number: 8094845 |
| 2. | 8094740 | [4] | PISTON & RINGS KIT | TORPISTON ASSY |
| 3. | 4892712 | [4] | PISTON PIN,38mm OD x 82mm L | TORPISTON PIN |
| 4. | 4892713 | [8] | SNAP RING,Int, M26.4 | TORSPRING LOCKWASHER Superseded by part number: 504093651 |
| 5. | 87316944 | [4] | SET,PISTON RINGS+0.4 | TORPISTONRING SET+0.4 |
| 6. | 87317252 | [4] | PISTON & RINGS KIT,0.4mm Oversize | TORPISTON ASSY. +0.4 |
