| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 01. | Y802109 | [1] | COVER | |
| 02. | Y802110 | [1] | COVER | |
| 03. | J901025 | [7] | BOLT | |
| 04. | A590910 | [11] | WASHER;SPRING | |
| 05. | A590110 | [11] | WASHER;PLANE | |
| 08. | 4053594 | [4] | CLAMP;PIPE | |
| 09. | J901045 | [4] | BOLT | |
| 11. | Y411781 | [1] | RUBBER | |
| 12. | 4443487 | [9] | CLIP | |
| 13. | Y802316 | [1] | STAY |
