| 2. |
86624713
|
[2] |
SPROCKET
|
NH
48T Superseded by part number: 87641160
|
| 3. |
87023062
|
[1] |
CHAIN (AG)
|
NH
Roller, #50, 5/8"-pitch, 77 Pitches Superseded by part number: 1791DX, 86595276
|
| 3. |
9849661
|
[1] |
CHAIN
|
NH
Roller, #50, 5/8"-pitch, 76 Pitches, Includes Ref. 51 Superseded by part number: 1791DX
|
| 4. |
86624712
|
[2] |
SPROCKET
|
NH
14T Superseded by part number: 87641197
|
| 4. |
87026284
|
[2] |
SPROCKET
|
PA
13T Superseded by part number: 87641197
|
| 5. |
86620026
|
[12] |
FLANGED BEARING
|
NH
|
| 6. |
156816C91
|
[6] |
BEARING HOUSING,28.6mm Hex x 72mm OD x 25mm W
|
IH
Superseded by part number: 84330069
|
| 7. |
86606411
|
[1] |
SUPPORT
|
NH
RH Superseded by part number: 87641813
|
| 8. |
86626141
|
[1] |
PICK-UP
|
PA
FRAME, 2M Dual Cam Wide Pickup
|
| 10. |
86598971
|
[1] |
ANGLE
|
NH
RH Superseded by part number: 87653255
|
| 11. |
86635914
|
[1] |
AUGER
|
PA
LH Superseded by part number: 84355521
|
| 12. |
86637746
|
[1] |
CAM
|
NH
RH, Outer Superseded by part number: 87023408
|
| 13. |
86637695
|
[1] |
CAM
|
NH
RH, Inner Superseded by part number: 87023407
|
| 14. |
86705250
|
[17] |
GUARD
|
PA
|
| 15. |
86552479
|
[1] |
CHAIN,RC50, 100 Links x 15.88mm = 1587.5mm
|
GI
Roller, Standard Duty, Chrome, RC50, 100 Pitches, Includes: Connector Link 86537460
|
| 15. |
87741470
|
[1] |
CHAIN,50, 100 Links x 15.88mm = 1587.5mm
|
PA
Roller, Optional Heavy Duty, RC50, 100 Pitches, Includes: Connector Link 86537460
|
| 16. |
86606410
|
[1] |
SUPPORT
|
NH
LH Superseded by part number: 87641822
|
| 17. |
86636966
|
[1] |
CAM
|
NH
LH, Outer
|
| 18. |
86636967
|
[1] |
CAM
|
NH
LH, Inner
|
| 19. |
86598970
|
[1] |
ANGLE
|
NH
LH Superseded by part number: 87653269
|
| 20. |
86610198
|
[4] |
INSERT,M6 x 1
|
NH
Threaded, M6
|
| 21. |
86643381
|
[14] |
GUARD
|
NH
|
| 22. |
86635916
|
[1] |
AUGER
|
PA
RH Superseded by part number: 84355439
|
| 23. |
86626559
|
[1] |
GUARD
|
PA
RH
|
| 24. |
86613200
|
[2] |
IDLER,89mm OD x 47.7mm W
|
NH
Eccentric, Nylon
|
| 25. |
86625888
|
[1] |
GUARD
|
PA
LH
|
| 26. |
86610199
|
[4] |
INSERT
|
PA
NUT Threaded, M6 Superseded by part number: 84272827
|
| 27. |
844-6020
|
[8] |
BOLT,Hvy Hex, M6 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 9804256
|
| 28. |
811-8030
|
[6] |
CARRIAGE BOLT,Sht Sq Nk, M8 x 1.25 x 30mm, Cl 8.8
|
CAS
|
| 29. |
844-10030
|
[18] |
BOLT,Hvy Hex, M10 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 9840672
|
| 30. |
614-10030
|
[4] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 43140
|
| 31. |
811-10030
|
[12] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 86512446
|
| 32. |
811-16050
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, M16 x 2 x 50mm, Cl 8.8
|
CAS
Superseded by part number: 412185
|
| 33. |
87039762
|
[124] |
SELF-TAP SCREW,Hex Wash Hd, 5/16"-18 x 5/8"
|
PA
Superseded by part number: 570821
|
| 36. |
87022926
|
[1] |
WASHER,35.05mm ID x 48.01mm OD x 2.14mm Thk
|
PA
.075" Thick
|
| 37. |
140016
|
[1] |
WASHER,M8 x 16mm OD x 1.6mm Thk
|
NH
Superseded by part number: 86624184
|
| 38. |
495-11066
|
[2] |
WASHER,5/8", SAE
|
CAS
Superseded by part number: 87365
|
| 39. |
322357
|
[8] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 40. |
322358
|
[6] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 41. |
140045
|
[34] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 44. |
825-2408
|
[6] |
FLANGE NUT,M8 x 1.25, Flg, Cl 8
|
CAS
Superseded by part number: 86505868
|
| 45. |
825-2410
|
[12] |
FLANGE NUT,M10 x 1.5, Flg, Cl 8
|
CAS
Superseded by part number: 9804278, 87778057
|
| 46. |
832-46416
|
[2] |
NUT,M16 x 2, Cl 8
|
CAS
Superseded by part number: 86000441
|
| 49. |
164086
|
[2] |
COTTER PIN
|
NH
Superseded by part number: 86013355
|
| 50. |
88529
|
[2] |
LOCK PIN,5.56mm OD x 44.45mm L, Slotted
|
NH
|
| 52. |
42472
|
[1] |
CONNECTING LINK
|
NH
Superseded by part number: 86537460
|
