神钢零件查询(F4GE9484D J601) - ENGINE - 5801370290 - 84301930.. (1/07-12/07) (3063.006) - TURBOCHARGER OIL LINES Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
251 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4895164 | [2] | SCREW,Hex, Flg Hd, M6 x 16 | TORHEXAGON BOLT |
| 2. | 4895107 | [1] | HYD CONNECTOR,11/16"-16 x M12 | TORTHREADED UNION, ASSY Superseded by part number: |
| 3. | 4899107 | [1] | O-RING,1.8mm Thk x 10.52mm ID | TORO-RING |
| 4. | 4899108 | [1] | O-RING,0.364mm ID x 0.07mm Width | TORO-RING Superseded by part number: 17277981 |
| 5. | 4899467 | [1] | GASKET | TORFLAT ENGINE GASKET |
| 6. | 4899519 | [1] | CLAMP,M16, M6 Bolt | TORBRACKET |
| 9. | 16677735 | [1] | SCREW,M12 x 25mm | TORHEXAGON BOLT, M12X25 MM |
| 12. | 2852197 | [2] | FLANGE NUT,M6 x 1 | TORHEXAGON NUT, M6 Superseded by part number: 17044625 |
| 13. | 16586225 | [1] | BOLT,M8 x 16mm | TORHEXAGON BOLT, M8X16 MM |
| 15. | 2852196 | [1] | BRACKET | TORFASTENING BRACKET Superseded by part number: 504053894 |
| 16. | 18137825 | [2] | BOLT,Hex, M6 x 16mm | TORHEXAGON BOLT, M6X16 |
