神钢零件查询(F4GE9484D J601) - ENGINE - 5801370290 - 84301930.. (1/07-12/07) (3150.007) - OIL - WATER HEAT EXCHANGER Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
363 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4899019 | [15] | SCREW,Hex Flg, M8 x 1.25 x 35 | TORHEXAGON BOLT, M8X35 MM |
| 4. | 4896404 | [1] | PLUNGER,10mm ID, 12mm OD, 15.44mm ID, 18.26mm OD | TORVALVE HOUSING |
| 5. | 4895045 | [1] | SPRING,Compression, 14.7mm OD x 66mm L | TORVALVE SPRING |
| 6. | 4899035 | [1] | O-RING,2.62mm Thk x 18.39mm ID | TORO-RING, UP TO # 155899 |
| 7. | J936365 | [1] | VALVE PRESSURE RELIE | CASVALVE Superseded by part number: 4896410 |
| 8. | 4899643 | [1] | FILTER HEAD | TORHEAT EXANGER BODY, ASSY |
| 9. | 4896406 | [1] | HEAT EXCHANGER | TOROIL COOLER Superseded by part number: 5801750729 |
| 10. | 2830559 | [1] | GASKET,0.5mm Thk | TORFLAT ENGINE GASKET |
| 11. | 4896409 | [1] | GASKET,1.55mm Thk | TORFLAT ENGINE GASKET |
| 12. | 4893391 | [1] | ADAPTER,M24 x 2 x M27 x 2 | TORTHREADED UNION |
| 13. | 504096409 | [1] | PLUG | TORTHREADED PLUG, ASSY, FROM # 155900 Superseded by part number: 2853781 |
| 14. | 17916280 | [1] | SEAL | TORO-RING, FROM # 155900 |
