神钢零件查询(F4GE9484D J619) - ENGINE - 5801584504 - YM02P00020P1 (11/12-) (10.103.AK) - FLYWHEEL & HOUSING Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
648 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4899026 | [2] | DOWEL,M18 x 10 | TOR |
| 2. | 2852324 | [2] | SCREW | TOR Superseded by part number: 16593625 |
| 2. | 2852326 | [11] | SCREW | TOR |
| 2. | 2852327 | [5] | BOLT,Flng, M12 x 1.75 x 80mm | TOR Superseded by part number: 16593224 |
| 2. | 2852100 | [3] | FLANGE BOLT,Hex, M8 x 1.25 x 16mm | TOR Superseded by part number: 16586225 |
| 3. | 2854075 | [1] | O-RING,0.103" Thk x 2.987" ID, -151 | TOR |
| 4. | 4895378 | [1] | BUTTON PLUG,M29.2 | TOR |
| 5. | 4895379 | [1] | O-RING,21.82mm ID x 3.53mm Width | TOR Superseded by part number: 17288480 |
| 6. | 2854073 | [1] | COVER | TOR Superseded by part number: 504115364 |
| 7. | 2852325 | [2] | SCREW | TOR Superseded by part number: 16592925 |
| 9. | 2854741 | [1] | COVER | TOR Superseded by part number: |
| 10. | 4895155 | [1] | COVER | TOR |
| 11. | 4899068 | [2] | BOLT,Flng, M8 x 1.25 x 16mm | BAS |
| 12. | NSS | [1] | NOT SOLD SEPARAT | CON |
