神钢零件查询(F4GE9484D J619) - ENGINE - 5801584504 - YM02P00020P1 (11/12-) (10.105.AB) - CONNECTING ROD Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
636 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2831298 | [4] | CONNECTING ROD | TORASSY, Incl 2 - 5 |
| 1. | 2831298R | [4] | REMAN-CONNECTING ROD | TOR |
| 1. | 2831298C | [4] | CORE-ROD CONNECTING | TORReturn Number |
| 2. | 4892708 | [1] | BUSHING,38.02mm ID x 41.01mm OD x 33.4mm L | TOR |
| 3. | 2831297 | [2] | FLANGE BOLT,Hex, M10 x 1.25 x 52mm, Cl 10.9 | TOR |
| 4. | NSS | [4] | NOT SOLD SEPARAT | CONCap, Incl in 1 |
| 5. | NSS | [4] | NOT SOLD SEPARAT | CONRod, Incl in 1 |
| 6. | 2856309 | [4] | CRANKSHAFT BEARING | BHB |
