纽荷兰零件查询(DC150.B) - CRAWLER DOZER TIER 2 (3/03-) (9.653[06]) - ROPS CAB WITH CONDITIONER - OPTIONAL CODE 784110171 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
751 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76092249 | [1] | HOUSING | LEC- CENTRAL LOWER |
| 2. | 76092250 | [1] | HOUSING | LEC- RIGHT LOWER |
| 3. | 76092219 | [1] | EVAPORATOR | LEC |
| 4. | 76093567 | [1] | SUPPORT | LEC- LEFT |
| 5. | 76093568 | [1] | SUPPORT | LEC- RIGHT |
| 6. | 76092218 | [2] | BLOWER | LEC |
| 7. | 76092252 | [1] | HOUSING | LEC- RIGHT |
| 8. | 76092253 | [1] | HOUSING | LEC- LEFT |
| 9. | 76093603 | [1] | COVER | LEC- LEFT |
| 10. | 76093571 | [1] | GRILLE | LEC |
| 11. | 76092242 | [1] | CAB FILTER | LEC |
| 12. | 76093604 | [1] | COVER | LEC- RIGHT |
| 13. | 76086485 | [2] | RUBBER RING | LEC |
| 14. | 76093593 | [1] | HALF-SHELL | LEC |
| 15. | 76093573 | [1] | KIT | LEC |
| 16. | 76093566 | [1] | DEFLECTOR | LEC |
| 17. | 15917007 | [12] | SCREW | LEC |
| 18. | 76093572 | [3] | SUPPORT | LEC |
| 19. | 76092272 | [1] | SEAL | LEC |
| 20. | 76093569 | [4] | PLATE | LEC |
| 21. | 76089309 | [1] | THERMOSTAT | LEC Superseded by part number: 87556056 |
| 22. | 76090399 | [1] | FLEXIBLE HOSE | LEC90° |
| 23. | 76090401 | [4] | HOSE CLAMP | LECD14 Superseded by part number: 76086497 |
| 24. | 76093618 | [1] | DRAINCOCK/TAP SUPPLY | LEC |
| 25. | 76093587 | [1] | PLATE | LEC |
| 26. | 76093574 | [15] | INSERT | LECM4 |
| 27. | 76093575 | [4] | INSERT | LECM6 |
| 28. | 76093565 | [1] | SEAL | LEC |
| 29. | 76093607 | [1] | HOSE | LEC90° |
| 30. | 76093608 | [1] | HOSE | LEC90° Superseded by part number: 76093607 |
| 31. | 76089543 | [1] | KIT | LEC Superseded by part number: 87363711 |
| 32. | 76092478 | [1] | BRACKET | LEC |
| 33. | 16043531 | [2] | SCREW,Hex, M8 x 1.25 x 22mm, Cl 10.9, Full Thd | LEC |
| 34. | 79011527 | [2] | WASHER,8.6mm ID x 22mm OD x 5mm Thk | LEC |
