| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 00. | Y411238 | [1] | AXLE;STEER | |
| 01. | Y909123 | [2] | TIRE ASS'Y | |
| 01A. | Y411243 | [1] | RIM;WHEEL | |
| 01B. | Y411226 | [1] | TIRE | |
| 04. | Y411407 | [1] | PIN | |
| 05. | A590127 | [2] | WASHER;PLANE | |
| 06. | A765050 | [2] | PIN;SPLIT | |
| 08. | Y410507 | [1] | BOX;TOOL | |
| 09. | J901025 | [4] | BOLT | |
| 10. | J950010 | [4] | NUT | |
| 11. | A590110 | [8] | WASHER;PLANE | |
| 12. | A590910 | [4] | WASHER;SPRING | |
| 14. | Y409595 | [8] | BOLT | |
| 15. | Y409596 | [8] | WASHER |
