日立零件查询（AR2000）DEPTH CONTROL DEVICE (REAR)(ML) Hitachi HOP online
广数供应链运营团队, 14 02月, 2025，浏览：
236 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| | +++++++ | | DEPTH CONTROL DEVICE | (REAR)(ML) |
| 02. | Y802115 | [1] | EXTERNAL POST | |
| 03. | Y801743 | [1] | BRACKET | |
| 04. | Y802116 | [1] | INTERNAL POST | |
| 05. | Y909199 | [1] | SCREW (CPL)(ML) | <for details: see separate page> |
| 06. | Y801773 | [2] | ARMS | |
| 07. | Y801775 | [1] | BRACKET | |
| 08. | Y909200 | [1] | WHEEL (CPL)(REAR)(ML) | <for details: see separate page> |
| 09. | Y909201 | [1] | PUSHER (ML) | <for details: see separate page> |
| 10. | Y409492 | [1] | SPACER | |
| 11. | Y409493 | [4] | LONG PIN | |
| 12. | Y409494 | [4] | SCREW | |
| 14. | J900625 | [4] | BOLT | |
| 15. | A590106 | [4] | WASHER;PLANE | |
| 16. | A590906 | [4] | WASHER;SPRING | |
| 17. | J780825 | [4] | BOLT;SOCKET | |
| 18. | J950010 | [4] | NUT | |
| 19. | A590910 | [4] | WASHER;SPRING | |
| 20. | A590120 | [8] | WASHER;PLANE | |
| 21. | A765025 | [8] | PIN;SPLIT | |
| 23. | J950012 | [1] | NUT | |
| 24. | A590912 | [1] | WASHER;SPRING | |
| 25. | A590908 | [4] | WASHER;SPRING | |
| 26. | J75481 | [1] | FITTING;GREASE | |
| 27. | J901435 | [4] | BOLT | |
| 28. | J901250 | [1] | BOLT | |
| 29. | Y409576 | [1] | PLATE | |
| 30. | M430306 | [2] | SCREW | |
| 31. | A590903 | [2] | WASHER;SPRING | |
| 32. | A590103 | [2] | WASHER;PLANE | |
| 33. | 4144017 | [1] | PIN;SPRING | |
| 34. | J260620 | [2] | BOLT;SEMS | |
| 34A. | J900620 | [1] | BOLT | |
| 34B. | A590106 | [1] | WASHER;PLANE | |
| 35. | Y301752 | [1] | NAME-PLATE | |
| 36. | M430606 | [3] | SCREW | |
| 37. | Y411929 | [1] | INDICATOR | |
| 39. | M500605 | [2] | NUT | |
