日立零件查询（AR2000）LIGHTING (MX) Hitachi HOP online
广数供应链运营团队, 14 02月, 2025，浏览：
450 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 00. | Y403961 | [2] | LAMP;HEAD | |
| 01. | Y411503 | [2] | BRACKET | |
| 02. | J901425 | [4] | BOLT | |
| 03. | A590914 | [6] | WASHER;SPRING | |
| 04. | 94-2816 | [2] | BUSHING;RUBBER | |
| 06. | 4336570 | [4] | LAMP;HEAD | |
| 07. | 4224631 | [4] | BRACKET | |
| 08. | 4254604 | [4] | HARNESS;WIRE | |
| 09. | A590906 | [4] | WASHER;SPRING | |
| 10. | M430613 | [4] | SCREW | |
| 12. | J901430 | [2] | BOLT | |
| 16. | Y403066 | [2] | LAMP | |
| 17. | J780512 | [8] | BOLT;SOCKET | |
| 18. | A590905 | [12] | WASHER;SPRING | |
| 19. | M500504 | [12] | NUT | |
| 20. | Y411502 | [8] | BRACKET | |
| 21. | J780516 | [4] | BOLT;SOCKET | |
| 22. | A590105 | [4] | WASHER;PLANE | |
