日立零件查询（AR2000）PORT BLOCK (MX) Hitachi HOP online
广数供应链运营团队, 14 02月, 2025，浏览：
823 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 00. | Y301819 | [1] | MANIFOLD | |
| 01. | J260816 | [6] | BOLT;SEMS | |
| 01A. | J900816 | [1] | BOLT | |
| 01B. | A590108 | [1] | WASHER;PLANE | |
| 02. | A852144 | [1] | ADAPTER;S | |
| 02A. | 4506418 | [1] | O-RING | |
| 03. | A852344 | [1] | ELBOW;S | |
| 03A. | 4506418 | [1] | O-RING | |
| 04. | 4222016 | [1] | TEE;S | |
| 04A. | 4506418 | [1] | O-RING | |
| 07. | Y412664 | [1] | MANIFOLD | |
| 08. | A852122 | [6] | ADAPTER;S | |
| 08A. | 957366 | [1] | O-RING | |
| 09. | A852322 | [1] | ELBOW;S | |
| 09A. | 957366 | [1] | O-RING | |
| 12. | Y414015 | [1] | MANIFOLD | |
| 13. | J260845 | [2] | BOLT;SEMS | |
| 13A. | J900845 | [1] | BOLT | |
| 13B. | A590108 | [1] | WASHER;PLANE | |
| 14. | A852422 | [1] | TEE;S | |
| 14A. | 957366 | [1] | O-RING | |
