| 1. |
87023419
|
[1] |
BRACKET
|
NH
|
| 2. |
86000448
|
[2] |
LATCH
|
NH
Rubber
|
| 3. |
9617869
|
[2] |
BUMPER,28.4mm W x 31.8mm L x 4.8mm Thk
|
NH
Rubber, 3/16" Thk
|
| 4. |
87036864
|
[1] |
TWINE BOX
|
PA
LH
|
| 5. |
87036862
|
[1] |
TWINE BOX
|
PA
RH
|
| 6. |
86551339
|
[4] |
DIVIDER
|
NH
|
| 7. |
29840
|
[4] |
SPRING,Compression, 11.91mm OD x 25.4mm L
|
NH
15/32" OD, 1" Free Length
|
| 8. |
9820171
|
[2] |
BRACKET
|
NH
|
| 9. |
87025227
|
[1] |
BRACKET
|
PA
RH
|
| 10. |
86617873
|
[1] |
ANGLE
|
NH
Superseded by part number: 84146192
|
| 11. |
86511841
|
[3] |
BOLT,Flng, M8 x 1.25 x 16mm, Full Thd, Cl 8.8
|
NH
|
| 12. |
412327
|
[4] |
CARRIAGE BOLT,Short Sq Nk, M6 x 1 x 40mm, Full Thd, Cl 8.8
|
NH
|
| 13. |
614-6020
|
[4] |
BOLT,Hex, M6 x 1 x 20mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 120100
|
| 14. |
905-8016
|
[6] |
BOLT,Hex Flg, M8 x 16mm
|
CAS
Superseded by part number: 86511478
|
| 15. |
614-8020
|
[4] |
BOLT,Hex, M8 x 1.25 x 20mm
|
CAS
Superseded by part number: 120104
|
| 16. |
614-12035
|
[4] |
BOLT,Hex, M12 x 1.75 x 35mm, Cl 8.8, Full Thd
|
IH
|
| 17. |
495-21031
|
[12] |
WASHER,1/4"
|
CAS
Superseded by part number: 80701, 72187262
|
| 19. |
322358
|
[4] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 20. |
140045
|
[4] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 21. |
140046
|
[12] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 23. |
832-46406
|
[8] |
NUT,M6 x 1, Cl 8
|
CAS
Superseded by part number: 353308
|
| 24. |
825-5148
|
[6] |
SERRATED NUT,M8, Flg Ser
|
CAS
Superseded by part number: 86505868
|
| 25. |
832-46412
|
[4] |
NUT,M12 x 1.75, Cl 8
|
CAS
Superseded by part number: 100038
|
| 26. |
825-2408
|
[2] |
FLANGE NUT,M8 x 1.25, Flg, Cl 8
|
CAS
Superseded by part number: 86505868
|
| 27. |
814-8050
|
[1] |
BOLT,Hex, M8 x 1.25 x 50mm, Cl 8.8
|
CAS
Superseded by part number: 43130
|
| 30. |
86618572
|
[6] |
GUIDE
|
NH
Spring Steel Superseded by part number: 86637283
|
| 31. |
86637283
|
[2] |
GUIDE
|
NH
Formed Style
|
