凯斯零件查询(RBX453) - CASE IH ROUND BALER (9/05-12/06) (08.55) - SHIELDS, BALE COMMAND™, TWINE, P.I.N. Y6N016414 & AFTER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
201 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87054829
|
[1] |
SHEET ASSY.
|
PA
RH Superseded by part number: 87661781
|
| 2. |
87046080
|
[2] |
ANGLE
|
PA
|
| 3. |
86643977
|
[3] |
ANTI-SKID STRIP,4” x 40”, Black
|
NH
|
| 4. |
0C
|
[1] |
ORDER COMPONENTS
|
NH
Electric Twine Wrap
|
| 8. |
87017062
|
[1] |
FLOOR
|
PA
|
| 10. |
87041094
|
[1] |
SHIELD
|
PA
Rubber
|
| 11. |
87054828
|
[1] |
SHEET ASSY.
|
PA
LH Superseded by part number: 87661780
|
| 17. |
844-6020
|
[1] |
BOLT,Hvy Hex, M6 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 9804256
|
| 19. |
844-8020
|
[12] |
BOLT,Hvy Hex, M8 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 9804258
|
| 20. |
811-8020
|
[13] |
CARRIAGE BOLT,Sht Sq Nk, M8 x 1.25 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 86507486
|
| 22. |
322357
|
[1] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 23. |
322358
|
[24] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 24. |
495-21038
|
[16] |
WASHER,5/16"
|
CAS
Superseded by part number: 80664, 72187263
|
| 25. |
86629542
|
[8] |
NUT,M8 x 1.25, Cl 8.8
|
ZED
|
| 26. |
825-2406
|
[1] |
FLANGE NUT,M6 x 1, Cl 8.8
|
CAS
Superseded by part number: 9804276
|
| 27. |
825-2408
|
[23] |
FLANGE NUT,M8 x 1.25, Flg, Cl 8
|
CAS
Superseded by part number: 86505868
|
| 37. |
87014355
|
[1] |
DOOR ASSY.
|
PA
North America, Includes: Decals
|
| 38. |
86511841
|
[7] |
BOLT,Flng, M8 x 1.25 x 16mm, Full Thd, Cl 8.8
|
NH
|
