日立零件查询（AR2000）OIL TANK (MX) Hitachi HOP online
广数供应链运营团队, 14 02月, 2025，浏览：
838 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 00. | Y600477 | [1] | TANK;OIL | |
| 01. | J901645 | [4] | BOLT | |
| 02. | A590916 | [4] | WASHER;SPRING | |
| 05. | Y802242 | [1] | PIPE:SUCTION | |
| 06. | Y802243 | [1] | PIPE:SUCTION | |
| 07. | A810165 | [2] | O-RING | |
| 09. | J271025 | [24] | BOLT;SEMS | |
| 09A. | J901025 | [1] | BOLT | |
| 09B. | J222010 | [1] | WASHER | |
| 11. | 4396437 | [2] | FILTER;SUCTION | |
| 12. | 8056948 | [1] | COVER | |
| 13. | 8065415 | [1] | COVER | |
| 14. | A810160 | [2] | O-RING | |
| 15. | 4141320 | [1] | BREATHER;AIR | |
| 18. | 8053499 | [1] | GAUGE;LEVEL | |
| 19. | 449558 | [4] | WASHER;SEAL | |
| 22. | 7031428 | [1] | CASE;FILTER | |
| 23. | A810200 | [1] | O-RING | |
| 24. | 4366198 | [1] | ELEMENT | |
| 25. | 4067978 | [1] | VALVE | |
| 26. | 4068540 | [1] | SPRING | |
| 27. | 3075276 | [1] | COVER | |
| 28. | A810230 | [1] | O-RING | |
| 29. | 4092534 | [1] | PLUG | |
| 29A. | 4509180 | [1] | O-RING | |
| 30. | J271030 | [6] | BOLT;SEMS | |
| 30A. | J901030 | [1] | BOLT | |
| 30B. | J222010 | [1] | WASHER | |
| 33. | 94-1705 | [1] | ADAPTER;S | |
| 34. | 94-4030 | [1] | COCK | |
| 35. | 94-2026 | [1] | PLUG | |
| 37. | 447483 | [1] | PLUG | |
