日立零件查询（AR2000）GENERATOR (PH) Hitachi HOP online
广数供应链运营团队, 14 02月, 2025，浏览：
320 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 00. | +++++++ | [1] | GENERATOR ASS'Y (PH) | <for details: see separate page> |
| 01. | +++++++ | [1] | ELECTRICAL ASS'Y (PH) | <for details: see separate page> |
| 03. | Y802431 | [1] | COVER | |
| 04. | J901016 | [4] | BOLT | |
| 05. | A590110 | [4] | WASHER;PLANE | |
| 06. | A590910 | [4] | WASHER;SPRING | |
| 08. | Y802429 | [1] | BASE | |
| 10. | Y802436 | [1] | BRACKET | |
| 11. | 4401503 | [1] | HOSE | |
| 12. | 4420981 | [1] | HOSE | |
| 13. | Y417385 | [1] | HOSE | |
| 14. | Y417386 | [1] | HOSE | |
| 15. | 4262930 | [1] | HOSE | |
