日立零件查询（AR2000）BURNER PIPING (PH) Hitachi HOP online
广数供应链运营团队, 14 02月, 2025，浏览：
793 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 00. | Y801779 | [1] | TUBE | |
| 01. | Y801780 | [1] | TUBE | |
| 02. | Y409805 | [1] | PIPE | |
| 03. | Y700816 | [1] | TUBE LINE | |
| 04. | Y801760 | [1] | HANGER | |
| 05. | Y409680 | [1] | BOLT;U | |
| 06. | Y301446 | [1] | BRACKET | |
| 07. | Y409679 | [6] | BOLT;U | |
| 10. | Y301451 | [1] | WASHER | |
| 11. | Y409681 | [2] | WASHER | |
| 12. | Y409688 | [1] | PLUG | |
| 13. | Y301455 | [1] | SHIELD | |
| 14. | Y410688 | [1] | COUPLING | |
| 15. | Y409687 | [1] | TUBE | |
| 16. | Y409686 | [1] | TUBE | |
| 17. | Y409685 | [1] | TUBE | |
| 18. | 4420354 | [7] | CLAMP;HOSE | |
| 19. | 4221275 | [1] | CLAMP;HOSE | |
| 20. | 4000853 | [3] | CLIP;PIPE | |
| 21. | 4053593 | [2] | CLAMP;PIPE | |
| 22. | 4137297 | [2] | SEAT;SCREW | |
| 23. | 4154651 | [3] | ADAPTER;S | |
| 24. | 4154656 | [2] | ELBOW;S | |
| 25. | 4154658 | [1] | ELBOW;S | |
| 26. | 4156433 | [2] | ELBOW | |
| 27. | 4215649 | [1] | ADAPTER;S | |
| 29. | 4221287 | [10] | ADAPTER;S | |
| 30. | 4221469 | [3] | HOSE;RUBBER | |
| 31. | 4345723 | [1] | ADAPTER;S | |
| 32. | 4351271 | [3] | ADAPTER;S | |
| 33. | 4363577 | [4] | SEAT;SCREW | |
| 34. | 94-0630 | [1] | ELBOW;S | |
| 35. | 94-0632 | [1] | ELBOW;S | |
| 36. | 94-0633 | [2] | ELBOW;S | |
| 37. | 94-0660 | [1] | TEE | |
| 38. | 94-0662 | [5] | TEE;S | |
| 40. | 94-0678 | [1] | SOCKET | |
| 42. | 94-0688 | [1] | REDUCER;S | |
| 43. | 94-1602 | [1] | REDUCER | |
| 45. | 94-1703 | [3] | ADAPTER;S | |
| 46. | 94-1704 | [2] | ADAPTER;S | |
| 47. | 94-1903 | [3] | ADAPTER;S | |
| 48. | 94-1701 | [1] | ADAPTER;S | |
| 49. | 94-2024 | [2] | PLUG | |
| 50. | A590908 | [18] | WASHER;SPRING | |
| 51. | A590910 | [6] | WASHER;SPRING | |
| 52. | J257218 | [8] | WASHER;SPRING | |
| 53. | A590912 | [8] | WASHER;SPRING | |
| 54. | J900612 | [3] | BOLT | |
| 55. | J931845 | [8] | BOLT | |
| 56. | J901045 | [6] | BOLT | |
| 57. | J901245 | [8] | BOLT | |
| 58. | J950008 | [14] | NUT | |
| 59. | J950018 | [8] | NUT | |
| 60. | J950012 | [8] | NUT | |
| 61. | M450832 | [4] | SCREW;SET | |
| 62. | Y407662 | [2] | ADAPTER;S | |
| 63. | Y410198 | [1] | HOSE;RUBBER | |
| 64. | Y410343 | [1] | ELBOW;S | |
| 65. | Y410341 | [1] | HOSE ASS'Y | |
| 6500. | +++++++ | [1] | HOSE | EE-07-19-041N(1-1/16-12UN) |
| 6501. | +++++++ | [1] | HOSE | GG-21-12-032N(3/4-16UNF) |
| 6502. | +++++++ | [1] | HOSE | EG-21-12-145N(3/4-16UNF) |
| 6503. | +++++++ | [1] | HOSE | EE-03-12-070N(3/4-16UNF) |
| 6504. | +++++++ | [1] | HOSE | EE-03-12-052N(3/4-16UNF) |
| 6505. | +++++++ | [1] | HOSE | EE-03-19-035N(1-1/16-12UN) |
| 6506. | +++++++ | [1] | HOSE | EG-21-06-130N(7/16-20UNF) |
| 6507. | +++++++ | [1] | HOSE | EE-07-06-170S(7/16-20UNF) |
| 6508. | +++++++ | [1] | HOSE | EE-07-06-700S(7/16-20UNF) |
| 6509. | +++++++ | [1] | HOSE | EE-21-06-130N(7/16-20UNF) |
| 6510. | +++++++ | [1] | HOSE | GG-21-12-115N(3/4-16UNF) |
| 6511. | +++++++ | [1] | HOSE | EG-21-12-085N(3/4-16UNF) |
| 66. | Y410320 | [1] | GAS;PROPANE | |
| 6600. | +++++++ | [1] | GAS BOMB | |
| 6601. | +++++++ | [1] | REGULATOR | |
| 6602. | +++++++ | [1] | HOSE | |
| 6603. | +++++++ | [1] | FITTING;HOSE | |
| 6604. | +++++++ | [2] | BAND | |
| 67. | 94-1608 | [2] | REDUCER | |
| 68. | 94-0615 | [1] | ELBOW;S | |
| 69. | Y971169 | [1] | COVER | |
| 70. | 94-1704 | [2] | ADAPTER;S | |
| 71. | 4221278 | [1] | ADAPTER;S | |
| 72. | Y410715 | [1] | UNION | |
| 73. | 4053594 | [4] | CLAMP | |
| 78. | J900816 | [4] | BOLT | |
| 79. | J900825 | [4] | BOLT | |
