纽荷兰零件查询(DC150LT) - CRAWLER DOZER (6/00-) (6.701[02]) - BATTERY - SEAT AND SUPPORT New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
998 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76066056 | [1] | ELECTRIC CABLE | TOR |
| 2. | 79090059 | [1] | NEG BATTERY CABLE | LEC- ASSY |
| 3. | 79020354 | [1] | GROUND STRAP | LEC |
| 4. | 79090060 | [1] | ELECTRIC CABLE | LEC- ASSY |
| 6. | 60093124 | [1] | PROTECTION CAP | MKT |
| 7. | 76066055 | [1] | POWER SOCKET | TOR |
| 9. | 12626231 | [2] | WASHER,10.2mm ID x 25mm OD x 3mm Thk | LEC |
| 10. | 10902631 | [4] | BOLT,Hex, M6 x 25mm, Cl 10.9 | BHB Superseded by part number: 10902633 |
| 11. | 14496431 | [8] | WASHER,6.4mm ID x 12.5mm OD x 1.6mm Thk | LEC Superseded by part number: 86588450 |
| 13. | 15896221 | [4] | NUT,Hex, M6, 5.20mm High, Cl 10 | ZED Superseded by part number: 86500688 |
| 14. | 16043131 | [3] | BOLT,Hex, M8 x 1.25 x 14mm, Cl 10.9, Full Thd | LEC |
| 17. | 10450490 | [3] | CLAMP,16mm, Coat, 9mm Bolt Hole, P Type | LEC9mm hole dia. Superseded by part number: |
| 20. | 14496531 | [3] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC Superseded by part number: 86624184 |
| 21. | 4950259 | [1] | PROTECTION CAP | LEC |
| 22. | 15896218 | [1] | NUT | TTF6X1X5 Superseded by part number: 86500688 |
| 23. | 11945008 | [1] | SCREW | LECSq. Hd, M6 x 1 x 30 Superseded by part number: 11945208 |
