日立零件查询（AR2000）OIK TANK (ML) Hitachi HOP online
广数供应链运营团队, 14 02月, 2025，浏览：
464 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 01. | Y801635 | [1] | COVER | |
| 02. | Y408409 | [1] | ADAPTER;S | |
| 03. | Y600346 | [1] | OIL TANK | |
| 04. | Y801738 | [1] | COLLECTOR | |
| 05. | Y408643 | [1] | GAUGE;LEVEL | |
| 07. | 4141320 | [1] | BREATHER;AIR | |
| 08. | Y408412 | [8] | RUBBER | |
| 09. | A590116 | [20] | WASHER;PLANE | |
| 10. | Y408732 | [4] | SHIM | |
| 11. | Y408731 | [4] | SHIM | |
| 12. | Y408730 | [4] | SHIM | |
| 13. | Y409372 | [2] | RUBBER WASHER | |
| 14. | J901600 | [16] | BOLT | |
| 16. | 4248606 | [4] | BOLT | |
| 17. | J950016 | [4] | NUT | |
| 18. | A590916 | [20] | WASHER;SPRING | |
| 21. | Y410815 | [2] | VALVE;BUTTERFLY | |
| 23. | 94-2026 | [1] | PLUG | |
| 24. | 94-4030 | [1] | COCK | |
| 25. | Y700854 | [1] | STRAINER | |
| 26. | J011245 | [12] | BOLT;SEMS | |
