| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 01. | Y409600 | [1] | CYL.;AIR | |
| 02. | 4120969 | [1] | END;ROD | |
| 03. | Y408640 | [1] | JOINT | |
| 04. | 4298746 | [1] | ELBOW;S | |
| 05. | Y409731 | [1] | HOSE | |
| 06. | A741232 | [1] | PIN | |
| 07. | A764020 | [1] | PIN;SPLIT | |
| 10. | Y971037 | [1] | PLATE | |
| 11. | J900825 | [2] | BOLT | |
| 12. | A590908 | [2] | WASHER;SPRING | |
| 13. | M500807 | [2] | NUT | |
| 15. | J900645 | [1] | BOLT | |
| 16. | A590106 | [2] | WASHER;PLANE | |
| 17. | M500605 | [1] | NUT | |
| 18. | A590906 | [1] | WASHER;SPRING |
