| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 01. | 88-0041 | [1] | OIL RADIATOR | THERMAL TRAN A0C-700-3-60-9 |
| 04. | J950012 | [6] | NUT | |
| 05. | A590112 | [4] | WASHER;PLANE | |
| 06. | A590912 | [2] | WASHER;SPRING | |
| 07. | Y410368 | [2] | ADAPTER;S | |
| 08. | 88-2097 | [1] | TEE | PARKER 8R50XSS |
| 09. | 88-2009 | [1] | TEE | PARKER 8R6XSS |
| 10. | 88-2098 | [1] | CONNECTOR | PARKER 8F650MXSS |
| 11. | 88-2011 | [1] | CONNECTOR | PARKER 8F50XSS |
| 12. | 88-0042 | [1] | VALVE;CHECK | REXROTH S10 A0.0/12 |
| 13. | 88-2012 | [3] | ELBOW | PARKER 8C50XSS |
| 15. | 88-2099 | [1] | TEE | PARKER 20R6MXSS |
| 16. | 88-2065 | [1] | REDUCER | PARKER 20-16TRTXSS |
| 17. | 88-2100 | [1] | REDUCER | PARKER 16-8TRTXSS |
| 18. | 88-2027 | [1] | NUT | PARKER 20BMTXSS |
| 19. | 88-2101 | [1] | NUT | PARKER 16BMTXSS |
| 22. | Y410216 | [4] | CLAMP | |
| 23. | Y410227 | [2] | SCREW;SET | |
| 24. | J901240 | [2] | BOLT | |
| 26. | Y801900 | [1] | BAR | |
| 27. | Y801857 | [1] | BAR | |
| 28. | J950010 | [2] | NUT | |
| 29. | A590910 | [2] | WASHER;SPRING | |
| 30. | A751648 | [2] | PIN | |
| 31. | A764025 | [4] | PIN;SPLIT | |
| 32. | A590116 | [4] | WASHER;PLANE | |
| 34. | Y971072 | [1] | SEAT;SCREW | |
| 35. | Y971065 | [1] | SEAT;SCREW | |
| 36. | J011025 | [2] | BOLT;SEMS | |
| 37. | J901240 | [2] | BOLT |
