纽荷兰零件查询(DC150LT) - CRAWLER DOZER (6/00-) (9.347[01]) - SALT TRACK CHAIN - SHOES (1GR.L=550MM) - OPTIONAL CODE 76029243 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
725 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76028761 | [2] | TRACK ASSY | LEC- ASSY |
| 2. | 79039483 | [43] | BUSHING | LEC |
| 3. | 79039482 | [43] | PIN | LEC |
| 4. | 79039493 | [86] | SPACER,37.25mm ID x 41.7mm OD x 9.3mm L | LEC |
| 5. | 79082288 | [86] | SEAL | LEC |
| 6. | 79039432 | [42] | TRACK LINK | LEC- RIGHT |
| 7. | 79039433 | [42] | TRACK LINK | LEC- LEFT |
| 8. | 79082285 | [1] | CONNECTING LINK | LEC- RIGHT IN ALTERNATIVE |
| 8. | 79083794 | [1] | CONNECTING LINK | LEC- RIGHT SPLIT IN ALTERNATIVE Superseded by part number: 79082285 |
| 9. | 79082286 | [1] | CONNECTING LINK | LEC- LEFT IN ALTERNATIVE |
| 9. | 79083803 | [1] | CONNECTING LINK | LEC- LEFT SPLIT IN ALTERNATIVE Superseded by part number: 79082286 |
| 10. | 79082287 | [43] | PLUG | LEC |
| 11. | 76030016 | [4] | FLANGE BOLT,Hex, M18 x 1.5 x 95mm, Cl 12.9 | LEC Superseded by part number: 79039444 |
| 12. | 76030015 | [168] | FLANGE BOLT,Hex, M18 x 1.5 x 55mm, Cl 12.9 | LEC Superseded by part number: 79039443 |
| 13. | 76029771 | [42] | TRACK SHOE | LEC- (1 GROUSER) |
| 14. | 76030017 | [168] | SQUARE NUT | LEC Superseded by part number: 79039445 |
| 15. | 76029772 | [1] | TRACK SHOE | LEC- (1 GROUSER) MASTER |
| 16. | 76029241 | [2] | TRACK ASSY | LEC- ASSY WITH SHOES (550mm) |
