神钢零件查询(F4GE9684B J605) - ENGINE 5801385851 - 84369828 (1/13-) (10.102.01) - ENGINE OIL SUMP (504084714) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
864 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4899020 | [2] | FLANGE BOLT,Hex, M8 x 1.25 x 20mm | TOR Superseded by part number: 16673635 |
| 2. | 4899091 | [18] | SCREW,Hex Flange Cap, M8 x 1.25 x 40.00mm | BAS |
| 3. | 4898301 | [1] | GASKET,0.42mm Thk | TOR |
| 4A. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 6. | 4897858 | [1] | SPACER | TOR |
| 8. | 4897861 | [1] | OIL PAN GASKET SET,17.3mm Thk | TOR |
| 10. | 4895291 | [2] | SCREW,Hex Flg, M10 x 1.5 x 20 | TOR |
