神钢零件查询(F4GE9684B J605) - ENGINE 5801385851 - 84369828 (1/13-) (10.102.02) - CRANKCASE COVERS (4894734) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
629 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4897026 | [1] | COVER | TORASSY Contains Ref.1A, 6 |
| 1A. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 2. | 4899078 | [5] | SCREW,Hex Flg, M8 x 1.25 x 45 | TOR |
| 3. | 4899063 | [8] | SCREW,Hex Flg, M8 x 1.25 x 30 | TOR |
| 4. | 4890832 | [1] | OIL SEAL,M70 x 100 x 12.5/16 | TOR Superseded by part number: |
| 5. | 4891209 | [2] | DOWEL,M13 x 8 L | TOR |
| 6. | 2852208 | [2] | INSERT | TOR Superseded by part number: |
