斗山零件查询PILOT PIPING(4) DX420LC-5(S/N:10001~10010) Doosan parts catalog online
广数供应链运营团队, 14 02月, 2025，浏览：
685 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| -. |
420212-08502
|
[-] |
|
|
| 101. |
410133-00004D2
|
[1] |
|
|
| 102. |
DS2121140
|
[1] |
|
|
| 103. |
2181-1950D2
|
[1] |
PLUG
|
|
| 104. |
S8000141
|
[2] |
O-RING
|
|
| 105. |
S8030061
|
[1] |
O-RING
|
|
| 12. |
DS2119256
|
[1] |
|
|
| 15. |
DS2121035
|
[1] |
|
|
| 16. |
DS2121038
|
[1] |
|
|
| 17. |
DS2121039
|
[1] |
|
|
| 201. |
2181-1950D2
|
[1] |
PLUG
|
|
| 202. |
2181-2815D5
|
[2] |
ELBOW
|
|
| 203. |
S8000111
|
[2] |
O-RING
|
|
| 204. |
S8000141
|
[1] |
O-RING
|
|
| 205. |
S8030061
|
[2] |
O-RING
|
|
| 22. |
DS2121373
|
[1] |
|
|
| 29. |
DS2143051
|
[1] |
|
|
| 35. |
K1057340
|
[1] |
SENSOR,PRESSURE
|
|
| 36. |
120202-00055
|
[4] |
|
|
| 37. |
120202-00057E
|
[4] |
|
|
| 45. |
2181-4133D2
|
[3] |
ADAPTER
|
|
| 49. |
2181-4133D44
|
[1] |
ADAPTER
|
|
| 5. |
920403-00076A
|
[2] |
|
|
| 56. |
2181-2295D4
|
[1] |
ELBOW
|
|
| 63. |
181-00121D4
|
[1] |
TEE
|
|
| 67. |
430225-00218
|
[2] |
|
|
| 68. |
430225-00218
|
[1] |
|
|
| 72. |
2181-1950D1
|
[1] |
PLUG
|
|
| 77. |
DS0025055
|
[8] |
BOLT;SET
|
|
| 86. |
S8000111
|
[2] |
O-RING
|
|
| 87. |
S8000141
|
[6] |
O-RING
|
|
| 89. |
S8030041
|
[2] |
O-RING
|
|
| 9. |
DS2119118
|
[1] |
|
|
| 90. |
S8030061
|
[9] |
O-RING
|
|
