| 1. |
86565877
|
[1] |
ROLLER
|
NH
5.56" Sledge Follower
|
| 2. |
86574943
|
[1] |
ROLLER
|
NH
Drive Superseded by part number: 87028612
|
| 3. |
86636982
|
[1] |
CHANNEL
|
NH
Scraper Mount
|
| 4. |
9845575
|
[1] |
SCRAPER BLADE
|
NH
|
| 5. |
614-8030
|
[8] |
BOLT,Hex, M8 x 1.25 x 30mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 43128
|
| 6. |
322
|
[8] |
WASHER,8.73mm ID x 42.07mm OD x 3.43mm Thk
|
NH
|
| 7. |
86637311
|
[1] |
FRAME
|
NH
Sledge
|
| 8. |
413-728
|
[1] |
BOLT,Hex, 7/16" - 14 x 1-3/4", Gr 5
|
IH
Superseded by part number: 84192879
|
| 9. |
29684
|
[2] |
WASHER,13.5mm ID x 50.8mm OD x 5.52mm Thk
|
NH
17/32" ID x 2" OD x 3/16" Thk
|
| 10. |
495-21050
|
[3] |
WASHER,7/16"
|
CAS
Superseded by part number: 81541
|
| 11. |
280980
|
[3] |
NUT,7/16"-14, GC
|
NH
|
| 12. |
86527218
|
[1] |
CHAIN,378mm L
|
NH
|
| 13. |
614-10030
|
[1] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 43140
|
| 14. |
492-11044
|
[1] |
LOCK WASHER,7/16"
|
CAS
Superseded by part number: 81547
|
| 15. |
495-21044
|
[2] |
WASHER,3/8"
|
CAS
Superseded by part number: 87779090, 80702
|
| 16. |
86637309
|
[1] |
ROLLER
|
NH
Stripper, Except Silage Special Superseded by part number: 87602972, 87390122
|
| 17. |
86637005
|
[1] |
ROLLER
|
NH
|
| 18. |
86637278
|
[1] |
ROLLER
|
NH
Starter
|
| 19. |
86637240
|
[1] |
ROLLER
|
NH
Floor
|
| 20. |
86637270
|
[1] |
DRIVEN SPROCKET
|
NH
Wide Pickup
|
| 21. |
66494
|
[1] |
CHAIN,60, 50 Links x 19.05mm = 952.5mm
|
NH
RC60, 3/4"-Pitch, 50 Pitches, Includes: (1) Connector Link
|
| 21A. |
86595275
|
[1] |
OFFSET LINK
|
ZED
- 60 Superseded by part number: 241-1716
|
| 22. |
86637189
|
[1] |
SHIELD
|
NH
|
| 23. |
86637188
|
[1] |
SHIELD
|
NH
Upper
|
| 24. |
9706726
|
[3] |
BOLT,Hex Flg, 3/8" - 16 x 1"
|
NH
|
| 25. |
9848760
|
[1] |
BELT,127.00 mm W x 1140.00 mm L
|
NH
|
| 28. |
86548820
|
[1] |
BELT,178.00 mm W x 1520.00 mm L
|
NH
Kit, Trash Baffle, Includes: Hardware & Instructions
|
| 31. |
86618701
|
[1] |
KIT
|
NH
Trash Baffle, Refer to Ref. 094
|
| 32. |
86636768
|
[2] |
PLATE
|
NH
|
| 33. |
811-12040
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, M12 x 1.75 x 40mm, Cl 8.8
|
CAS
Superseded by part number: 328754
|
| 35. |
80679
|
[2] |
LOCK WASHER,1/20.507 CST ZND
|
NH
|
| 36. |
829-1412
|
[2] |
NUT,M12, Cl 10.9
|
CAS
Superseded by part number: 337475
|
| 38. |
86636900
|
[1] |
SPACER
|
NH
|
| 39. |
673
|
[1] |
WASHER,29mm ID x 41mm OD x 1.52mm Thk
|
NH
|
