凯斯零件查询(RBX461) - CASE IH ROUND BALER (12/01-12/02) (073) - WIDE PICKUP, FRAME Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
154 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
86636656
|
[1] |
GUARD ASSY.
|
NH
Frame, Pickup
|
| 2. |
855657
|
[2] |
PAD
|
NH
Rubber
|
| 3. |
825-5148
|
[6] |
SERRATED NUT,M8, Flg Ser
|
CAS
Superseded by part number: 86505868
|
| 4. |
811-8020
|
[6] |
CARRIAGE BOLT,Sht Sq Nk, M8 x 1.25 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 86507486
|
| 5. |
86633239
|
[1] |
ANGLE
|
NH
RH
|
| 6. |
86633238
|
[1] |
ANGLE
|
NH
LH
|
| 7. |
86634548
|
[2] |
DEFLECTOR
|
NH
|
| 8. |
412093
|
[4] |
SELF-TAP SCREW
|
NH
M6 x 1 x 12
|
