凯斯零件查询(RBX461) - CASE IH ROUND BALER (12/01-12/02) (078) - WIDE PICKUP, REEL, FINGERS, DOUBLE CAM Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
139 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
86634546
|
[2] |
COUPLING
|
NH
|
| 2. |
86543385
|
[1] |
SHAFT
|
NH
Hex
|
| 3. |
86628669
|
[4] |
ANGLE BAR
|
NH
|
| 4. |
326210
|
[2] |
GROOVED PIN
|
NH
Type A, 5/16" x 1-3/4"
|
| 5. |
733-5040
|
[1] |
COTTER PIN,M5 x 40
|
CAS
Superseded by part number: 130011
|
| 6. |
86634545
|
[1] |
CAM
|
NH
|
| 7. |
84350126
|
[8] |
CAM FOLLOWER,1/2" - 20 x 38mm OD x 54.5mm L
|
NH
|
| 8. |
703960
|
[1] |
WASHER
|
NH
1-1/4" OD Superseded by part number: 87642988
|
| 9. |
86634532
|
[1] |
WASHER,31.96mm ID x 44.5mm OD x 1.9mm Thk
|
CAS
1-3/4" OD
|
| 10. |
65319
|
[4] |
WASHER,13.1mm ID x 25.4mm OD x 3.68mm Thk
|
NH
|
| 11. |
88130
|
[4] |
NUT,1/2"-20, GC
|
NH
|
| 12. |
87394242
|
[48] |
TORSION SPRING,Coiled, 2 Prong, 186.5mm L
|
NH
Pickup, Curved, Premium, Standard
|
| 12. |
87607074
|
[48] |
TINE
|
NH
Pickup, Curved, Economy, Optional
|
| 13. |
86634547
|
[4] |
SHAFT
|
NH
|
| 14. |
832-46410
|
[1] |
NUT,M10 x 1.5, Cl 8
|
CAS
Superseded by part number: 100037
|
| 15. |
614-10050
|
[1] |
BOLT,Hex, M10 x 1.5 x 50mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 120113
|
| 16. |
9618968
|
[48] |
WASHER,0.41" ID x 0.78" OD x 0.1" Thk
|
NH
.781" OD, Heat Treated
|
| 17. |
614-10030
|
[44] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 43140
|
| 18. |
86634554
|
[2] |
SUPPORT
|
NH
End Guard
|
| 19. |
86618417
|
[23] |
GUARD
|
NH
Pickup
|
| 20. |
412093
|
[1] |
SELF-TAP SCREW
|
NH
M6 x 1 x 12
|
| 21. |
86636662
|
[4] |
SHAFT
|
NH
|
| 22. |
86634528
|
[1] |
CAM
|
NH
|
