| 1. |
86636552
|
[1] |
BEARING CAP
|
NH
|
| 2. |
9617265
|
[2] |
BAND
|
NH
|
| 3. |
86978168
|
[1] |
ARM
|
NH
Take Up
|
| 4. |
86511324
|
[8] |
WASHER,13mm ID x 24mm OD x 2.5mm Thk
|
NH
Superseded by part number: 87364
|
| 5. |
832-46412
|
[4] |
NUT,M12 x 1.75, Cl 8
|
CAS
Superseded by part number: 100038
|
| 6. |
814-12045
|
[4] |
BOLT,Hex, M12 x 1.75 x 45mm, Cl 8.8
|
CAS
Superseded by part number: 9628065
|
| 7. |
9842288
|
[1] |
ROLLER,88.9mm OD x 1142mm L
|
NH
3.50" Superseded by part number: 84356720
|
| 7. |
86611236
|
[1] |
ROLLER,101.6mm OD x 1142mm L
|
NH
Rubber Covered for Silage
|
| 8. |
86516321
|
[2] |
SUPPORT
|
NH
Superseded by part number: 87654791
|
| 9. |
8050825
|
[4] |
BEARING, ROLLER, CYL,38.1 mm ID x 80 mm OD x 30.163 mm
|
L
Superseded by part number: F82059
|
| 10. |
86627635
|
[4] |
BOLT,Hex, M12 x 1.75 x 30mm, Cl 10.9
|
NH
Cap, HH, CL8.8, M12 x 30, 6.5 Head Height
|
| 11. |
9823372
|
[1] |
SHAFT,1135mm L
|
NH
Includes: (2) Ref. 18
|
| 12. |
86500663
|
[1] |
ROLLER,114.3mm OD x 1145mm L
|
NH
4.50", Includes: Ref. 14 Superseded by part number: 84601406
|
| 14. |
86500662
|
[2] |
BEARING ASSY
|
NH
|
| 15. |
614-12030
|
[2] |
BOLT,Hex, M12 x 1.75 x 30mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 9706687
|
| 16. |
86516322
|
[2] |
SUPPORT
|
NH
Superseded by part number: 87654792
|
| 17. |
NSS
|
[2] |
NOT SOLD SEPARAT
|
CON
Spring, Refer to Fig. 030
|
| 18. |
838-5526
|
[10] |
LOCK PIN,M5 x 26, Slotted
|
CAS
Superseded by part number: 82848074, 130045
|
| 19. |
86978164
|
[2] |
LINK,520mm L
|
NH
|
| 20. |
86636659
|
[3] |
SPACER,10.28mm ID x 15.85mm OD x 21.84mm L
|
NH
|
| 21. |
814-10050
|
[3] |
BOLT,Hex, M10 x 1.5 x 50mm, Cl 8.8
|
CAS
Superseded by part number: 120069, 47110242
|
| 22. |
832-46410
|
[3] |
NUT,M10 x 1.5, Cl 8
|
CAS
Superseded by part number: 100037
|
| 23. |
86637229
|
[2] |
LINK,489mm L
|
NH
|
| 24. |
432-1224
|
[1] |
COTTER PIN,3/16" x 1-1/2"
|
CAS
Superseded by part number: 80754
|
| 25. |
495-11106
|
[2] |
WASHER,1", SAE
|
CAS
Superseded by part number: 87367
|
| 26. |
633038
|
[2] |
THREADED ROD,3/4" - 10 x 11-1/2" L
|
NH
|
| 27. |
495-21081
|
[2] |
WASHER,3/4"
|
CAS
Superseded by part number: 86511191
|
| 28. |
425-1012
|
[2] |
NUT,3/4"-10, G5
|
CAS
Superseded by part number: 280954
|
| 29. |
32406
|
[2] |
SPACER,25.9mm ID x 31.5mm OD x 16.8mm L
|
NH
|
