凯斯零件查询(RBX461) - CASE IH ROUND BALER (12/01-12/02) (014) - SLEDGE FOLLOWER ROLLER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
565 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
827-12045
|
[2] |
BOLT,Hex, M12 x 1.75 x 45mm, Cl 10.9, Full Thd
|
CAS
Superseded by part number: 86639031
|
| 2. |
87030468
|
[2] |
HUB
|
PA
Superseded by part number: 87398962
|
| 3. |
86553395
|
[2] |
SUPPORT
|
NH
|
| 5. |
86548282
|
[2] |
BALL BEARING,29.41mm ID x 90mm OD x 30.2mm W, Square Bore
|
NH
|
| 6. |
86553396
|
[2] |
BEARING ASSY,30.23mm ID x 90mm OD x 30.2mm W, SQUARE BORE
|
NH
Includes: Ref. 5
|
| 8. |
86565877
|
[1] |
ROLLER
|
NH
5.56", Includes: (2) Ref. 6
|
