| 1. |
712735
|
[1] |
KNOB
|
NH
|
| 2. |
86619298
|
[1] |
DOOR
|
NH
|
| 3. |
86628711
|
[1] |
BRACKET
|
NH
RH
|
| 4. |
811-8020
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, M8 x 1.25 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 86507486
|
| 5. |
825-5148
|
[1] |
SERRATED NUT,M8, Flg Ser
|
CAS
Superseded by part number: 86505868
|
| 6. |
844-8020
|
[1] |
BOLT,Hvy Hex, M8 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 9804258
|
| 7. |
280129
|
[2] |
NUT,1/4"-20
|
NH
|
| 8. |
495-21031
|
[1] |
WASHER,1/4"
|
CAS
Superseded by part number: 80701, 72187262
|
| 9. |
413-456
|
[2] |
BOLT,Hex, 1/4" - 20 x 3-1/2", Gr 5
|
CAS
Superseded by part number: 280492
|
| 10. |
86619300
|
[1] |
SHIELD
|
NH
|
| 11. |
825-1408
|
[4] |
NUT,M8, Cl 8
|
CAS
Superseded by part number: 43362
|
| 12. |
86543545
|
[4] |
GUIDE
|
NH
|
| 13. |
86551339
|
[4] |
DIVIDER
|
NH
Black
|
| 14. |
9617869
|
[1] |
BUMPER,28.4mm W x 31.8mm L x 4.8mm Thk
|
NH
|
| 15. |
86643175
|
[1] |
FLOOR
|
NH
Twine Box
|
| 16. |
86501026
|
[1] |
SHIELD
|
NH
|
| 17. |
280736
|
[2] |
NUT,5/16"-18, GC
|
NH
|
| 18. |
905-10025
|
[2] |
BOLT,Hex Flg, M10 x 25mm
|
CAS
Superseded by part number: 274251
|
| 19. |
86978165
|
[1] |
TUBE,1181 mm L
|
NH
|
| 20. |
9805974
|
[1] |
ROD
|
NH
|
| 21. |
86628714
|
[1] |
LATCH
|
NH
|
| 22. |
825-1410
|
[1] |
NUT,M10, Cl 8
|
CAS
Superseded by part number: 100016
|
| 23. |
495-21038
|
[3] |
WASHER,5/16"
|
CAS
Superseded by part number: 80664, 72187263
|
| 24. |
37836
|
[1] |
SPACER,1" - 8 x 8"
|
NH
Split
|
| 25. |
811-10060
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 60mm, Cl 8.8
|
CAS
Superseded by part number: 86512447
|
| 26. |
86628712
|
[1] |
BRACKET
|
NH
LH
|
| 27. |
26538
|
[1] |
SPRING
|
NH
Superseded by part number: 86611329
|
| 28. |
86511448
|
[2] |
COTTER PIN,0.148" Dia x 3.31" L
|
NH
9/64" x 3-5/16" Superseded by part number: 80033778
|
| 29. |
9823255
|
[2] |
GUIDE
|
NH
|
| 30. |
86636896
|
[2] |
STOP
|
NH
|
| 31. |
86630116
|
[1] |
TWINE BOX
|
NH
|
| 32. |
9800095
|
[1] |
ROD
|
NH
Superseded by part number: 89800095
|
| 33. |
86619296
|
[1] |
DOOR ASSY.
|
NH
|
| 34. |
9840986
|
[1] |
CLIP
|
NH
|
| 35. |
86520136
|
[2] |
RIVET,Aluminum, .196” Dia
|
NH
|
| 38. |
86627083
|
[2] |
ANGLE
|
NH
Mount
|
| 39. |
28114
|
[4] |
U-BOLT
|
NH
#10-24 x 1-15/16"
|
| 40. |
492-11010
|
[8] |
LOCK WASHER,#10
|
CAS
Superseded by part number: 80684
|
| 41. |
225-14110
|
[8] |
NUT,#10-24
|
CAS
Superseded by part number: 87304
|
| 42. |
128104
|
[1] |
BUMPER
|
NH
|
| 43. |
825-5146
|
[1] |
SERRATED NUT,M6, Flg Ser
|
CAS
Superseded by part number: 86511444
|
| 44. |
86620939
|
[1] |
SHIELD
|
NH
RH
|
| 45. |
12255
|
[1] |
SPRING
|
NH
1-3/4" Lg.
|
| 46. |
E9NN16N738AB
|
[1] |
LATCH
|
NH
1/4 Turn Superseded by part number: 81866169
|
| 47. |
9806113
|
[1] |
LATCH
|
NH
|
| 48. |
86979427
|
[1] |
SPACER
|
NH
|
| 49. |
832-46408
|
[1] |
NUT,M8 x 1.25, Cl 8
|
CAS
Superseded by part number: 86528579
|
| 50. |
86631044
|
[1] |
SHIELD
|
NH
Includes: Ref. 75
|
| 51. |
814-10060
|
[1] |
BOLT,Hex, M10 x 1.5 x 60mm, Cl 8.8
|
CAS
Superseded by part number: 120070
|
| 52. |
811-10020
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 86512422
|
| 53. |
495-11047
|
[4] |
WASHER,7/16", SAE
|
CAS
Superseded by part number: 87363
|
| 54. |
492-11044
|
[4] |
LOCK WASHER,7/16"
|
CAS
Superseded by part number: 81547
|
| 56. |
844-6016
|
[1] |
BOLT,Hvy Hex, M6 x 16mm, Cl 8.8
|
CAS
Superseded by part number: 9804255
|
| 57. |
632732
|
[2] |
LATCH
|
NH
Slide
|
| 58. |
86620935
|
[1] |
STEP
|
NH
LH
|
| 59. |
86620936
|
[1] |
STEP
|
NH
RH
|
| 60. |
86520316
|
[1] |
SHIELD
|
NH
|
| 61. |
284422
|
[2] |
BUMPER
|
NH
|
| 62. |
614-8020
|
[1] |
BOLT,Hex, M8 x 1.25 x 20mm
|
CAS
Superseded by part number: 120104
|
| 65. |
86620940
|
[1] |
SHIELD
|
NH
LH
|
| 66. |
768632
|
[2] |
IDLER WHEEL,100.84mm OD x 20.32mm W
|
NH
Pulley
|
| 67. |
825-2408
|
[6] |
FLANGE NUT,M8 x 1.25, Flg, Cl 8
|
CAS
Superseded by part number: 86505868
|
| 68. |
9805610
|
[1] |
DOOR
|
NH
Superseded by part number: 89847910
|
| 70. |
43129
|
[2] |
BOLT,Hex, M8 x 1.25 x 40mm, LH Thd, Cl 8.8
|
NH
Superseded by part number: 16044024
|
| 71. |
495-21044
|
[1] |
WASHER,3/8"
|
CAS
Superseded by part number: 87779090, 80702
|
| 72. |
86580794
|
[2] |
GUIDE
|
NH
|
| 73. |
86580795
|
[2] |
SPACER
|
NH
|
| 74. |
811-8030
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, M8 x 1.25 x 30mm, Cl 8.8
|
CAS
|
| 75. |
9826789
|
[1] |
DANGER DECAL,180mm x 90mm H
|
NH
DANGER, English
|
| 75. |
9827448
|
[1] |
DANGER DECAL
|
NH
French
|
