| 1. |
9800151
|
[1] |
BAR PLATE
|
NH
|
| 2. |
9824949
|
[1] |
SHIELD
|
NH
Superseded by part number: 89824949
|
| 3. |
9824948
|
[1] |
WEAR STRIP
|
NH
|
| 4. |
811-8020
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, M8 x 1.25 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 86507486
|
| 5. |
825-5148
|
[1] |
SERRATED NUT,M8, Flg Ser
|
CAS
Superseded by part number: 86505868
|
| 6. |
844-8020
|
[1] |
BOLT,Hvy Hex, M8 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 9804258
|
| 7. |
844-6016
|
[1] |
BOLT,Hvy Hex, M6 x 16mm, Cl 8.8
|
CAS
Superseded by part number: 9804255
|
| 8. |
825-5146
|
[1] |
SERRATED NUT,M6, Flg Ser
|
CAS
Superseded by part number: 86511444
|
| 9. |
86619301
|
[1] |
LID
|
NH
|
| 10. |
86000448
|
[2] |
LATCH
|
NH
|
| 11. |
844-6020
|
[1] |
BOLT,Hvy Hex, M6 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 9804256
|
| 12. |
495-21031
|
[1] |
WASHER,1/4"
|
CAS
Superseded by part number: 80701, 72187262
|
| 13. |
832-46406
|
[1] |
NUT,M6 x 1, Cl 8
|
CAS
Superseded by part number: 353308
|
| 14. |
9617447
|
[1] |
ROLL PIN
|
NH
Rod
|
| 15. |
86619297
|
[1] |
SUPPORT
|
NH
Housing
|
| 17. |
86636789
|
[1] |
SHIELD
|
NH
RH
|
| 18. |
614-8016
|
[4] |
BOLT,Hex, M8 x 1.25 x 16mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 16043224
|
| 19. |
E9NN16N738AB
|
[2] |
LATCH
|
NH
1/4 Turn Superseded by part number: 81866169
|
| 20. |
9840986
|
[2] |
CLIP
|
NH
|
| . . |
84821
|
[2] |
SCREW,Truss HD, #10 - 24 x 1/2"
|
NH
|
| . . |
492-11010
|
[2] |
LOCK WASHER,#10
|
CAS
Superseded by part number: 80684
|
| . . |
225-14110
|
[2] |
NUT,#10-24
|
CAS
Superseded by part number: 87304
|
| . . |
86520136
|
[1] |
RIVET,Aluminum, .196” Dia
|
NH
|
| 24. |
86619086
|
[1] |
DOOR ASSY.
|
NH
|
| 25. |
86628084
|
[2] |
BRACKET
|
NH
|
| 26. |
9617869
|
[15] |
BUMPER,28.4mm W x 31.8mm L x 4.8mm Thk
|
NH
|
| 27. |
86637161
|
[1] |
FILLER
|
NH
RH
|
| 28. |
86637234
|
[1] |
STOP
|
NH
RH
|
| 29. |
86619291
|
[1] |
SHIELD
|
NH
|
| 30. |
86619292
|
[1] |
PLATE
|
NH
Wrapper, RH
|
| 31. |
86636792
|
[1] |
SHIELD
|
NH
Top
|
| 32. |
86636757
|
[1] |
PLATE
|
NH
Wrapper, LH
|
| 33. |
252687
|
[8] |
WASHER,0.34" ID x 0.75" OD x 0.09" Thk
|
NH
|
| 34. |
86547710
|
[1] |
EMBLEM
|
ZED
KIT SMV
|
| 36. |
86637159
|
[1] |
FILLER
|
NH
LH
|
| 37. |
86637390
|
[1] |
BRACKET
|
NH
|
| 38. |
86637191
|
[1] |
STOP
|
NH
LH
|
| 39. |
86619087
|
[1] |
DOOR ASSY.
|
NH
LH
|
| 40. |
86636755
|
[1] |
SHIELD
|
NH
|
| 41. |
9804219
|
[2] |
ROD
|
NH
|
| 42. |
86618403
|
[1] |
PANEL ASSY.
|
NH
|
| 45. |
86510335
|
[2] |
BRACKET
|
PA
Stop
|
| . . |
614-8020
|
[2] |
BOLT,Hex, M8 x 1.25 x 20mm
|
CAS
Superseded by part number: 120104
|
| . . |
322358
|
[2] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| . . |
825-1408
|
[2] |
NUT,M8, Cl 8
|
CAS
Superseded by part number: 43362
|
| 46. |
86551340
|
[2] |
BAR
|
NH
Black
|
| 47. |
495-21056
|
[2] |
WASHER,1/2"
|
CAS
Superseded by part number: 72187265, 80700
|
| 48. |
495-21044
|
[4] |
WASHER,3/8"
|
CAS
Superseded by part number: 87779090, 80702
|
| 49. |
814-8050
|
[1] |
BOLT,Hex, M8 x 1.25 x 50mm, Cl 8.8
|
CAS
Superseded by part number: 43130
|
| 50. |
832-46408
|
[2] |
NUT,M8 x 1.25, Cl 8
|
CAS
Superseded by part number: 86528579
|
| 51. |
277552
|
[2] |
SPRING
|
NH
|
| 52. |
86614489
|
[2] |
HINGE
|
NH
|
| 53. |
86614490
|
[2] |
ROD
|
NH
|
| 54. |
86630117
|
[1] |
DOOR ASSY.
|
NH
LH, Includes: Ref. 60
|
| 55. |
86614485
|
[1] |
END ASSY.
|
NH
LH
|
| 56. |
86630118
|
[1] |
DOOR ASSY.
|
NH
RH, Includes: Ref. 60
|
| 57. |
86614487
|
[1] |
END ASSY.
|
NH
RH
|
| 58. |
86628666
|
[1] |
SUPPORT
|
NH
|
| 59. |
495-11047
|
[1] |
WASHER,7/16", SAE
|
CAS
Superseded by part number: 87363
|
| 60. |
86631518
|
[2] |
DANGER DECAL
|
NH
English
|
| 60. |
86632801
|
[2] |
DECAL
|
NH
DANGER, French
|
