纽荷兰零件查询(DC180.B) - CRAWLER DOZER TIER 2 (3/03-) (9.177[02]) - FAN - SOUND SUPPRESSION - OPTIONAL CODE 76080610 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
394 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76080597 | [1] | BLOWER | LEC |
| 3. | 11108231 | [4] | BOLT,Hex, M10 x 100mm, Cl 10.9 | LEC Superseded by part number: 43253 |
| 4. | 71477103 | [1] | DECAL,111dB, 90mm x 110mm | LEC |
| 5. | 14496631 | [4] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | LEC Superseded by part number: 14496621 |
| 6. | 76080572 | [2] | GUARD | LEC |
| 7. | 76080671 | [2] | STRAP | LEC |
| 8. | 76080573 | [2] | GUARD | LEC |
| 9. | 76080672 | [2] | STRAP | LEC |
| 10. | 16043431 | [16] | SCREW,Hex, M8 x 1.25 x 20mm, Cl 10.9, Full Thd | BHB Superseded by part number: 16605534 |
| 11. | 12645031 | [16] | WASHER,8.45mm ID x 21mm OD x 3mm Thk | LEC |
