沃尔沃零件查询L45F Water pump and thermostat housingNone NoneNoneNoneAutodata Volvo online
广数供应链运营团队, 14 02月, 2025，浏览：
941 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
VOE20726083
|
[1] |
Coolant Pump
|
|
| 2. |
VOE20405691
|
[1] |
Gasket
|
|
| 3. |
VOE20412324
|
[9] |
Screw
|
|
| 4. |
VOE20412325
|
[2] |
Sealing ring
|
|
| 5. |
VOE20405693
|
[1] |
Plug
|
|
| 6. |
VOE13947622
|
[1] |
Plane gasket
|
|
| 7. |
VOE20502245
|
[1] |
Plug
|
|
| 8. |
VOE21260062
|
[1] |
Thermostat housing
|
|
| 9. |
VOE20798076
|
[1] |
O-ring
|
|
| 10. |
VOE20792140
|
[4] |
Hexagon screw
|
|
| 11. |
VOE13947281
|
[2] |
Gasket
|
|
| 12. |
VOE20551429
|
[1] |
Fitting
|
|
| 13. |
VOE20460936
|
[1] |
Hollow screw
|
|
| 14. |
VOE20460312
|
[1] |
Thermostat
|
|
| 15. |
VOE20459961
|
[1] |
Sealing ring
|
|
| 16. |
VOE13947628
|
[1] |
Plane gasket
|
|
| 17. |
VOE20459195
|
[1] |
Plug
|
|
| 18. |
VOE20817900
|
[1] |
Connection pipe
|
|
| 19. |
VOE20412324
|
[2] |
Screw
|
|
| 20. |
VOE20496587
|
[1] |
Pulley
|
|
| 21. |
VOE20405898
|
[3] |
Screw
|
|
| 22. |
|
[1] |
V-belt
|
|
| 23. |
VOE13947622
|
[1] |
Plane gasket
|
|
| 24. |
VOE20412313
|
[1] |
Hose connection
|
|
| |
VOE21727935
|
[1] |
Water Pump Kit
|
|
