凯斯零件查询(RBX462) - CASE IH ROUND BALER (1/03-7/05) (18.06) - ROTATING BEACON KIT Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
317 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87027251
|
[1] |
DIA KIT, HARVESTER
|
PA
Rotating Beacon, Includes: Installation Instructions
|
| 2. |
9513421
|
[1] |
BEACON
|
ZED
|
| 3. |
9513422
|
[1] |
BASE
|
ZED
Socket
|
| 4. |
87024644
|
[1] |
ANGLE
|
PA
RBX452 Superseded by part number: 87371399
|
| 4. |
87024646
|
[1] |
ANGLE
|
PA
RBX462 Superseded by part number: 87371399
|
| 5. |
87024645
|
[1] |
CLAMP
|
PA
RBX452
|
| 5. |
87024647
|
[1] |
CLAMP
|
PA
RBX462
|
| 6. |
442227
|
[1] |
BULB
|
ZED
12V, 55W Superseded by part number: 14151095
|
| 7. |
87032480
|
[1] |
HARNESS
|
PA
|
| 8. |
844-8030
|
[2] |
BOLT,Hex, M8 x 1.25 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 87779272, 9804260
|
| 9. |
825-2408
|
[2] |
FLANGE NUT,M8 x 1.25, Flg, Cl 8
|
CAS
Superseded by part number: 86505868
|
| 10. |
322358
|
[2] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 11. |
263117
|
[20] |
CABLE TIE,292.1mm L, Nylon, Black
|
NH
CABLE STRAP
|
| 12. |
441167
|
[2] |
TERMINAL CONNECTOR,Tin, 2.5 - 4.0mm
|
ZED
Male, 2.5-4
|
| 13. |
441159
|
[2] |
CONTACT HOUSING,Female, 1 Pole
|
ZED
Insulator Superseded by part number: 87675193
|
| 14. |
86508819
|
[1] |
POWER SOCKET
|
ZED
Male, Single Pole
|
